Autonomous Agent Architectures

16 minute read

“Architecture beats prompting: build autonomous agents with clear state, strict tool boundaries, and measurable stop conditions.”

1. What “autonomous” actually means (and what it doesn’t)

An autonomous agent is a system that can take a high-level goal and make a sequence of decisions—often across multiple steps and tools—without a human telling it exactly what to do next.

Autonomy is not one feature; it’s a bundle:

Goal-driven behavior: it keeps the objective in mind across steps
Tool use: it calls external tools (search, code execution, databases, APIs)
Statefulness: it maintains memory about what it tried and what happened
Adaptation: it changes strategy when a path fails
Stopping: it knows when to stop (done, failed, needs human input)

What autonomy is not:

“Run forever”
“Do everything automatically”
“No guardrails”

In production, the best autonomous agents are bounded: they’re highly capable inside a restricted sandbox, and they degrade gracefully when the task exceeds their safe envelope.

2. The central idea: autonomy is a control loop

Most autonomous agents can be modeled as a loop:

Observe -> Decide -> Act -> Observe -> ...

In practice, the loop looks like this:

Observe: collect inputs (user request + state + tool outputs)
Decide: select the next action (plan, tool call, ask user, stop)
Act: run the action (tool execution or internal reasoning)
Update state: record what happened
Stop condition: check if done / failed / needs escalation

This “agent loop” is why architecture matters: you’re building a tiny decision-making system, not just generating text.

3. Reference architecture: Planner–Executor–Verifier (PEV)

One of the most reliable architectures is to separate the agent into roles:

User Request
   |
   v
Planner  -> produces a plan + constraints + stop conditions
   |
   v
Executor -> runs tools / performs actions per plan
   |
   v
Verifier -> checks correctness, safety, and completeness
   |
   v
Finalizer -> summarizes outcome + evidence + next actions (if any)

Why this works

The Planner is optimized for strategy and decomposition.
The Executor is optimized for doing, with minimal reasoning.
The Verifier is optimized for skepticism.

This reduces “single-model overconfidence.” Many agent failures are “the model confidently chose a bad step and then rationalized it.” Verification breaks that pattern.

4. State model: your agent needs more than chat history

A production-grade agent usually needs structured state like:

Objective: what success means (including constraints)
Plan: a list of steps and dependencies
Progress: what’s done, what’s blocked
Facts: verified information (with provenance)
Tool cache: avoid repeating identical tool calls
Failures: what didn’t work (negative memory)
Budget: tokens, time, tool calls, money

A simple state shape (conceptual) is:

{
  "objective": "...",
  "constraints": ["..."],
  "plan": [{"id": 1, "task": "...", "status": "pending"}],
  "facts": [{"key": "...", "value": "...", "source": "..."}],
  "attempts": [{"step_id": 2, "action": "...", "result": "failed", "why": "..."}],
  "budget": {"max_steps": 10, "spent_steps": 3}
}

Junior engineer tip: your orchestration code should treat this state as the source of truth. The LLM should read it and propose updates, but your code should validate and persist it.

4.5 Memory architecture inside autonomy: short-term, long-term, and “facts”

Autonomous agents often fail because they treat “memory” as one big blob. In practice, you want to separate three layers:

4.5.1 Short-term context (what the model can “see” right now)

This is the recent conversation plus a small state snapshot. It’s limited by context length and expensive to resend.

Engineering implication: don’t append forever. Use summaries and a sliding window, and keep the prompt focused on the current step.

4.5.2 Long-term memory (what the system can retrieve when needed)

This is a store of documents, notes, and prior outcomes. The key property is that it is retrieval-based, not “always in prompt.”

Engineering implication: retrieve only what’s relevant for the current step. If you retrieve too much, the agent gets distracted and loses the goal.

4.5.3 Facts (what you consider verified)

Facts are not just “things the model said.” Facts should be:

backed by evidence (citations, tool outputs, test results)
stored as structured key/value
ideally with a timestamp and provenance (where did this come from?)

Engineering implication: treat your verifier as the gatekeeper for facts. Executors can propose facts; verifiers decide what becomes a fact.

If you separate these layers, your agent becomes calmer: it stops re-litigating old decisions and stops hallucinating “facts” that aren’t grounded.

5. Planning strategies: from linear plans to DAGs

5.1 Linear plans (good starting point)

A linear plan is a list:

Do A
Then do B
Then do C

This is easy to implement and easy to debug.

5.2 DAG plans (when parallelism matters)

If tasks can run in parallel (independent tools), a DAG plan is better:

Node: a step
Edge: dependency

Example:

Step 1: fetch docs
Step 2: fetch logs
Step 3: parse docs (depends on 1)
Step 4: parse logs (depends on 2)
Step 5: synthesize (depends on 3 and 4)

If you have a tool execution environment that supports parallelism, DAG planning can drastically reduce latency.

Further reading (optional): for structured plans and strict schemas, see Structured Output Patterns.

6. Tool boundaries: autonomy without tool discipline is chaos

Tools are where agents touch the real world. So tools need strict boundaries:

6.1 Principle of least privilege

Give the agent the smallest toolset required for the task.

Example:

Research agent: search, fetch, extract
Execution agent: run_code (sandboxed)
Writer agent: no tools, only formatting

6.2 Separate read tools from write tools

Many safety incidents come from mixing reads and writes:

agent reads untrusted content
agent immediately uses write tools based on that content

A common pattern is:

browsing phase: read-only tools
action phase: write tools only after explicit validation + (optionally) human approval

6.3 Tool contracts and validation

Every tool call should be validated:

schema validation (types)
semantic validation (allowed domains, allowed file paths, max sizes)
budget validation (rate limits, cost caps)

This is not optional; it’s how you prevent “autonomous” from turning into “uncontrolled.”

6.5 The “Supervisor + Workers” variant (when tasks are complex)

The Planner–Executor–Verifier split works well inside a single “agent.” For bigger tasks, you often get better reliability by introducing a Supervisor that delegates to workers (specialists).

Supervisor (goal + state owner)
   |
   +--> Research Worker (read-only tools)
   |
   +--> Execution Worker (sandboxed code)
   |
   +--> Writer Worker (formatting, docs)
   |
   +--> Verifier Worker (checks claims/tests)

Why this helps

The supervisor maintains one canonical state (plan, budgets, stop conditions).
Workers are smaller and easier to keep “on role.”
You can enforce tool boundaries per worker (least privilege).

The orchestration contract

To avoid chaos, each worker should receive:

a task (one sentence)
required inputs (documents, files, structured state fields)
expected output schema
strict budget (max tool calls, max tokens)

And each worker should return:

result (structured)
evidence (quotes, logs, test output)
confidence
next_questions (optional)

This looks boring, but boring is good. It gives you systems behavior instead of “vibes.”

7. Stop conditions: the most underrated part of autonomy

A good autonomous agent stops for the right reason. Common stop states:

SUCCESS: objective met
FAILURE: objective cannot be met under constraints
NEEDS_INPUT: missing info, ambiguous request
NEEDS_APPROVAL: high-risk action requires human confirmation

7.1 Concrete success checks

Success should be measurable. Instead of “I think I’m done,” define checks like:

output contains required fields
tests pass (if code produced)
citations support claims (if research task)
API response indicates success

7.2 Budget-based stopping

Stop when budgets are exceeded:

max tool calls
max steps
max token spend
max wall time

These budgets keep systems predictable and cost-controlled.

7.5 A practical “done” checklist (copy/paste)

Many agents fail because they don’t know what “done” means. A simple checklist helps:

Requirements met: did we satisfy all constraints (format, scope, safety)?
Evidence present: if we made claims, do we have citations/quotes or test output?
No open TODOs: are there unresolved plan steps marked “required”?
No red flags: did a verifier flag anything as unsafe or unsupported?
Stop reason recorded: success, failure, needs input, needs approval.

As a junior engineer, treat this like an API response contract: “we only return SUCCESS if the checklist passes.”

8. Failure recovery: safe autonomy means safe retries

Autonomous agents fail constantly: bad sources, flaky APIs, wrong assumptions.

Good recovery patterns:

8.1 Retry with evidence

On failure, feed the exact error back to the planner/executor and ask for a minimal fix.

8.2 Strategy pivoting

If one approach fails twice, change strategy:

try a different tool
narrow the task scope
ask for user clarification

8.3 Escalation

If a task is high risk or repeatedly failing, stop and escalate:

request human review
return partial progress + what’s missing

Further reading (optional): see Error Handling and Recovery for a deeper taxonomy of failures and circuit breaker patterns.

8.5 Avoiding the “agent spiral”: negative memory + repetition detectors

A common failure mode is the agent spiral:

it tries a tool call
it fails
it retries the same call with minor variations
it burns budget without making progress

Two very effective mitigations:

8.5.1 Negative memory (“what not to do again”)

Store structured “failures” in state:

action attempted (tool name + args hash)
error class (timeout, 403, parsing error)
short reason (“blocked domain”, “rate limit”, “schema mismatch”)

Then instruct the planner: “Do not propose actions whose hash is in failures unless you change strategy.”

8.5.2 Repetition detectors

Hard-stop when:

the same tool call is repeated 3 times
the same plan step is re-entered without new evidence

When tripped, the agent must either:

ask the user a question
switch strategy
escalate

This is how you prevent infinite loops and unpredictable costs.

9. Observability: autonomy without traces is un-debuggable

When agents run multi-step loops, you need visibility:

what did the agent try?
why did it choose that tool?
where did time/money go?
where did it get stuck?

At minimum, log:

decision per step
tool calls + arguments (redacted)
tool results (summarized, referenced for large outputs)
token usage and latency
stop reason

Further reading (optional): see Observability and Tracing for span-level tracing and evaluation hooks.

9.5 Measuring autonomy: metrics that matter

If you want autonomous agents to improve over time, you need metrics that represent “agent health,” not just “model quality.”

Good practical metrics:

Success rate by intent: % of tasks completed successfully (per task type)
Steps-to-success: median and p95 number of steps
Tool error rate: % of tool calls failing (per tool)
Retry rate: average retries per step
Budget burn: tokens/cost per success (and p95)
Escalation rate: how often tasks require approval or human help
Verifier disagreement rate: how often verifier rejects executor outputs

The interesting part is not the average; it’s the outliers. Autonomy tends to fail in long tails: weird inputs, flaky dependencies, ambiguous goals. Your tracing should help you find those quickly.

10. Safety patterns for autonomy (real-world guardrails)

10.1 Allowlists for high-risk operations

For file, database, or infra operations:

allowlist directories, tables, endpoints
block wildcards
require explicit scope

10.2 “Dry run” mode

Before applying changes, produce a diff or plan and verify it:

generate patch
run tests
review diff
only then apply

10.3 Human-in-the-loop gates

Use approval gates for:

destructive actions (delete, overwrite)
actions with money impact (billing)
actions with privacy impact (PII)

10.4 Prompt injection boundaries

Autonomous agents often browse. Treat external content as untrusted data and never allow it to rewrite instructions.

Further reading (optional): see Web Browsing Agents for a concrete “tainted input” browsing pipeline.

10.6 Governance: treat prompts, tools, and policies as “code”

When autonomy goes wrong in production, you want the same thing you want in normal software: version control and change management.

Practical governance patterns:

Prompt/version pinning: store prompts in git and record prompt versions in traces.
Tool registry: a single source of truth for tool schemas, safety rules, and allowlists.
Policy tests: unit tests for “dangerous behavior” (no network in sandboxes, no writes without approval).
Canary releases: ship prompt/policy updates to a small percentage of traffic and watch your key metrics.

This is how you avoid: “we changed one line in a prompt and now the agent behaves completely differently.”

10.5 Implementation sketch: a minimal autonomous loop (pseudocode)

Below is a conceptual skeleton. The key is that the orchestrator (your code) owns the loop, budgets, and validation.

def run_agent(objective: str, state: dict) -> dict:
    for step_idx in range(state["budget"]["max_steps"]):
        decision = llm.decide({
            "objective": objective,
            "state": state,
            "policy": {
                "no_unvalidated_writes": True,
                "max_tool_calls_per_step": 1
            }
        })

        if decision["type"] == "ASK_USER":
            return {"status": "NEEDS_INPUT", "question": decision["question"], "state": state}

        if decision["type"] == "STOP":
            return {"status": decision["status"], "state": state, "summary": decision.get("summary")}

        if decision["type"] == "TOOL_CALL":
            tool_name, args = decision["tool"], decision["args"]

            validate_tool_call(tool_name, args, state)  # allowlists, budgets, schemas
            result = tools.run(tool_name, args)
            state = update_state_with_result(state, decision, result)

            if is_repetition(state):
                return {"status": "FAILURE", "reason": "REPETITION_DETECTED", "state": state}

    return {"status": "FAILURE", "reason": "STEP_BUDGET_EXCEEDED", "state": state}

This is intentionally strict. Autonomy in production is about controlled freedom.

If you want the LLM to generate a plan, do it as a structured object (and validate it), then execute it in this loop.

11. Case study: an “Autonomous DevOps Helper” (bounded autonomy)

Goal: assist with incident response in a safe way.

Safe design:

Observe: fetch logs/metrics (read-only tools)
Diagnose: propose hypotheses + tests
Execute tests: run safe queries only
Recommend: suggest changes (no write tools)
Escalate: if change required, produce a patch and request approval

What this avoids:

the agent restarting services repeatedly
applying risky configuration changes without review
“fixing” the incident by masking symptoms

The best autonomy here is “autonomous diagnosis + assisted remediation.”

11.5 Case study: “Autonomous research assistant” with citations (bounded browsing)

Goal: produce a short report with citations on a topic.

Safe architecture:

Planner: generate 3–5 queries and a report outline (budgeted).
Research worker: browse the web using read-only tools and extract evidence.
Verifier: enforce “quote supports claim” and require ≥2 sources for key claims.
Writer: draft the report using only verified claims + citations.
Stop: success only if citations exist and verifier passes.
