Distributed ML Systems

Design distributed ML systems that scale to billions of predictions: Master replication, sharding, consensus, and fault tolerance for production ML.

Problem Statement

Design a distributed machine learning system that can:

1. Handle billions of predictions per day across multiple regions
2. Train models on terabytes of data across multiple machines
3. Serve models with low latency (<100ms) and high availability (99.99%)
4. Handle failures gracefully without data loss or service disruption
5. Scale horizontally by adding more machines

Why Distributed Systems?

The fundamental constraint: A single machine can’t handle:

Data:

• Training data: 10TB+ (won’t fit in RAM)
• Model size: 100GB+ (large language models, embeddings)
• Inference load: 100,000 requests/sec (CPU melts 🔥)

Computation:

• Training time: Days/weeks on single GPU
• Inference: Can’t serve millions of users from one server

Geography:

• Users worldwide: Tokyo, London, New York, São Paulo
• Latency: Can’t serve Tokyo users from Virginia (150ms+ RTT)

Reliability:

• Single machine fails → Entire service down ❌
• Need redundancy and fault tolerance

Real-World Scale Examples

Company	Scale	Challenge
Google Search	8.5B searches/day	Distributed indexing + serving
Netflix	200M users, 1B hours/day	Personalization at scale
Uber	19M trips/day	Real-time matching + prediction
Meta	3B users	Social graph + recommendation

Common pattern: All use distributed ML systems!

---

Understanding Distributed Systems Fundamentals

What Makes Systems “Distributed”?

Definition: Multiple computers working together as one system.

Simple analogy: Restaurant kitchen

• Single machine: One chef makes everything (slow, bottleneck)
• Distributed: Multiple chefs, each specializing (fast, parallel)

But coordination is hard:

• How do chefs know what to cook?
• What if a chef is sick?
• How to avoid making duplicate orders?

These are distributed systems problems!

The CAP Theorem

CAP Theorem states: You can only have 2 of 3:

1. Consistency (C): All nodes see same data at same time
2. Availability (A): System always responds (even if some nodes down)
3. Partition Tolerance (P): System works despite network failures

In practice: Network partitions happen, so you must have P. Real choice: Consistency (CP) vs Availability (AP)

Example scenarios:

Scenario: Network split between US and EU data centers

CP System (Choose Consistency):
- Reject writes until partition healed
- Data stays consistent
- But users in EU can't use system! ❌

AP System (Choose Availability):
- Accept writes in both regions
- Users happy! ✓
- But data may conflict later (eventual consistency)

For ML systems:

• Training: CP (want consistent data)
• Serving: AP (availability critical for user experience)

Key Concepts for Junior Engineers

1. Horizontal vs Vertical Scaling

Vertical Scaling (Scale UP):
  1 machine → Bigger machine
  4 CPU     → 64 CPU
  16GB RAM  → 512GB RAM

  Pros: Simple, no code changes
  Cons: Expensive, limited (can't buy infinite RAM), single point of failure

Horizontal Scaling (Scale OUT):
  1 machine → 10 machines

  Pros: Cheaper, unlimited, fault-tolerant
  Cons: Complex (distributed systems problems!)

ML systems need horizontal scaling because:

• Data too big for one machine
• Training too slow on one machine
• Serving load too high for one machine

2. Replication vs Sharding

Replication: Same data on multiple machines

Machine 1: [A, B, C, D]
Machine 2: [A, B, C, D]  ← Same data!
Machine 3: [A, B, C, D]

Use case: High availability, load distribution
Example: Model weights replicated to 100 servers

Sharding: Different data on each machine

Machine 1: [A, B]
Machine 2: [C, D]  ← Different data!
Machine 3: [E, F]

Use case: Data too big for one machine
Example: Training data split across 10 machines

3. Synchronous vs Asynchronous

Synchronous: Wait for response before continuing

result = call_other_service()  # Block here
process(result)  # Wait until call returns

• Pros: Simple, consistent
• Cons: Slow (latency adds up)

Asynchronous: Don’t wait, continue immediately

future = call_other_service_async()  # Don't block
do_other_work()  # Continue immediately
result = future.get()  # Get result when needed

• Pros: Fast, better resource usage
• Cons: Complex, harder to debug

---

Architecture Patterns

Pattern 1: Master-Worker (for Training)

Use case: Distributed model training

┌─────────────────────────────────────────────┐
│              MASTER NODE                     │
│  • Coordinates workers                       │
│  • Aggregates gradients                      │
│  • Updates global model                      │
└────────┬──────────┬──────────┬──────────────┘
         │          │          │
    ┌────▼────┐ ┌──▼─────┐ ┌──▼─────┐
    │Worker 1 │ │Worker 2│ │Worker 3│
    │ GPU 1   │ │ GPU 2  │ │ GPU 3  │
    │Batch 1  │ │Batch 2 │ │Batch 3 │
    └─────────┘ └────────┘ └────────┘

How it works:

1. Master distributes data batches to workers
2. Each worker computes gradients on its batch
3. Workers send gradients back to master
4. Master averages gradients, updates model
5. Master broadcasts updated model to workers
6. Repeat

Python implementation:

class MasterNode:
    """
    Master node for distributed training

    Coordinates multiple worker nodes
    """

    def __init__(self, model, workers):
        self.model = model
        self.workers = workers
        self.global_step = 0

    def train_step(self, data_batches):
        """
        One distributed training step

        1. Send model to workers
        2. Workers compute gradients
        3. Aggregate gradients
        4. Update model
        """
        # Distribute work to workers
        futures = []
        for worker, batch in zip(self.workers, data_batches):
            # Send model and data to worker
            future = worker.compute_gradients_async(
                self.model.state_dict(),
                batch
            )
            futures.append(future)

        # Wait for all workers (synchronous)
        gradients = [future.get() for future in futures]

        # Aggregate gradients (averaging)
        avg_gradients = self._average_gradients(gradients)

        # Update model
        self.model.update(avg_gradients)
        self.global_step += 1

        return self.model

    def _average_gradients(self, gradients_list):
        """Average gradients from all workers"""
        avg_grads = {}

        for param_name in gradients_list[0].keys():
            # Average this parameter's gradients
            param_grads = [g[param_name] for g in gradients_list]
            avg_grads[param_name] = sum(param_grads) / len(param_grads)

        return avg_grads

class WorkerNode:
    """
    Worker node that computes gradients
    """

    def __init__(self, worker_id, device='cuda'):
        self.worker_id = worker_id
        self.device = device

    def compute_gradients_async(self, model_state, batch):
        """
        Compute gradients on local batch

        Returns: Future that will contain gradients
        """
        import concurrent.futures

        executor = concurrent.futures.ThreadPoolExecutor()
        future = executor.submit(
            self._compute_gradients,
            model_state,
            batch
        )

        return future

    def _compute_gradients(self, model_state, batch):
        """Actually compute gradients"""
        import torch

        # Load model
        model = load_model()
        model.load_state_dict(model_state)
        model.to(self.device)

        # Forward + backward
        loss = model(batch)
        loss.backward()

        # Extract gradients
        gradients = {
            name: param.grad.cpu()
            for name, param in model.named_parameters()
        }

        return gradients

Challenges:

1. Straggler problem: Slowest worker delays everyone
   • Solution: Asynchronous updates, backup tasks
2. Communication overhead: Sending gradients is expensive
   • Solution: Gradient compression, local updates
3. Fault tolerance: What if worker crashes?
   • Solution: Checkpoint frequently, redistribute work

Pattern 2: Load Balancer + Replicas (for Serving)

Use case: Serving ML predictions at scale

                  ┌──────────────┐
    Requests ──→  │Load Balancer │
                  │  (Round Robin)│
                  └──────┬───────┘
                         │
        ┌────────────────┼────────────────┐
        ▼                ▼                ▼
   ┌─────────┐      ┌─────────┐     ┌─────────┐
   │ Replica 1│      │Replica 2│     │Replica 3│
   │  Model  │      │ Model   │     │ Model   │
   │+ Cache  │      │+ Cache  │     │+ Cache  │
   └─────────┘      └─────────┘     └─────────┘

Benefits:

• High availability: If one replica dies, others handle load
• Load distribution: 10K req/sec across 10 replicas = 1K each
• Zero-downtime deploys: Update replicas one at a time

Implementation:

class LoadBalancer:
    """
    Simple round-robin load balancer

    Distributes requests across healthy replicas
    """

    def __init__(self, replicas):
        self.replicas = replicas
        self.current_index = 0
        self.health_checker = HealthChecker(replicas)
        self.health_checker.start()

    def route_request(self, request):
        """
        Route request to healthy replica

        Uses round-robin for simplicity
        """
        # Get healthy replicas
        healthy = self.health_checker.get_healthy_replicas()

        if not healthy:
            raise Exception("No healthy replicas available!")

        # Round-robin selection
        replica = healthy[self.current_index % len(healthy)]
        self.current_index += 1

        # Forward request
        try:
            response = replica.predict(request)
            return response
        except Exception as e:
            # Retry with different replica
            return self._retry_request(request, exclude=[replica])

    def _retry_request(self, request, exclude=None):
        """Retry failed request on different replica"""
        exclude = exclude or []
        healthy = [
            r for r in self.health_checker.get_healthy_replicas()
            if r not in exclude
        ]

        if not healthy:
            raise Exception("All replicas failed")

        return healthy[0].predict(request)

class HealthChecker:
    """
    Continuously monitor replica health

    Marks unhealthy replicas so LB doesn't route to them
    """

    def __init__(self, replicas, check_interval=10):
        self.replicas = replicas
        self.check_interval = check_interval
        self.health_status = {r: True for r in replicas}
        self.running = False

    def start(self):
        """Start health checking in background"""
        import threading

        self.running = True
        self.thread = threading.Thread(
            target=self._health_check_loop,
            daemon=True
        )
        self.thread.start()

    def _health_check_loop(self):
        """Continuously check replica health"""
        import time

        while self.running:
            for replica in self.replicas:
                is_healthy = replica.health_check()
                self.health_status[replica] = is_healthy

                if not is_healthy:
                    print(f"⚠️ Replica {replica.id} unhealthy!")

            time.sleep(self.check_interval)

    def get_healthy_replicas(self):
        """Get list of currently healthy replicas"""
        return [
            replica for replica in self.replicas
            if self.health_status[replica]
        ]

Pattern 3: Pub-Sub for Async Communication

Use case: Model updates, feature updates, async tasks

                    ┌───────────────┐
                    │  Message Bus  │
                    │    (Kafka)    │
                    └───────┬───────┘
                            │
            ┌───────────────┼───────────────┐
            ▼               ▼               ▼
    ┌──────────────┐ ┌──────────────┐ ┌──────────────┐
    │ Subscriber 1 │ │ Subscriber 2 │ │ Subscriber 3 │
    │ Update model │ │ Update cache │ │ Log metrics  │
    └──────────────┘ └──────────────┘ └──────────────┘

When to use:

• Model deployment: Notify all servers to reload model
• Feature updates: Broadcast new feature values
• Logging: Send metrics/logs asynchronously
• Training triggers: Data arrives → trigger training job

Implementation:

class PubSubSystem:
    """
    Publish-Subscribe system for async communication

    Publishers send messages, subscribers receive them
    """

    def __init__(self):
        self.subscribers = {}  # topic -> [subscribers]

    def subscribe(self, topic, callback):
        """
        Subscribe to a topic

        Args:
            topic: Topic name (e.g., 'model.updated')
            callback: Function to call when message received
        """
        if topic not in self.subscribers:
            self.subscribers[topic] = []

        self.subscribers[topic].append(callback)
        print(f"✓ Subscribed to {topic}")

    def publish(self, topic, message):
        """
        Publish message to topic

        All subscribers will receive it asynchronously
        """
        if topic not in self.subscribers:
            return

        for callback in self.subscribers[topic]:
            # Call asynchronously (non-blocking)
            import threading
            thread = threading.Thread(
                target=callback,
                args=(message,)
            )
            thread.start()

        print(f"📢 Published to {topic}: {message}")

# Example usage
pubsub = PubSubSystem()

# Subscriber 1: Model server that reloads on updates
def reload_model(message):
    print(f"🔄 Reloading model: {message['model_version']}")
    # Load new model...

pubsub.subscribe('model.updated', reload_model)

# Subscriber 2: Cache that invalidates on updates
def invalidate_cache(message):
    print(f"🗑️ Invalidating cache for: {message['model_version']}")
    # Clear cache...

pubsub.subscribe('model.updated', invalidate_cache)

# Publisher: Training job publishes when done
def training_complete(model_path, version):
    pubsub.publish('model.updated', {
        'model_path': model_path,
        'model_version': version,
        'timestamp': time.time()
    })

# Trigger
training_complete('s3://models/v123', 'v123')
# Both subscribers receive message asynchronously!

---

Handling Failures

Key principle: In distributed systems, failures are normal, not exceptional!

Types of Failures

1. Machine failure: Server crashes
2. Network partition: Network splits, can’t communicate
3. Slow nodes: “Stragglers” delay entire system
4. Corrupted data: Silent data corruption
5. Cascading failures: One failure triggers others

Fault Tolerance Strategies

1. Replication (Multiple Copies)

class ReplicatedStorage:
    """
    Store data on multiple nodes

    If one fails, others have copy
    """

    def __init__(self, nodes, replication_factor=3):
        self.nodes = nodes
        self.replication_factor = replication_factor

    def write(self, key, value):
        """
        Write to multiple nodes

        Succeeds if majority succeed (quorum)
        """
        # Pick nodes to write to
        target_nodes = self._pick_nodes(key, self.replication_factor)

        # Write to all (parallel)
        import concurrent.futures
        with concurrent.futures.ThreadPoolExecutor() as executor:
            futures = [
                executor.submit(node.write, key, value)
                for node in target_nodes
            ]

            # Wait for majority
            successes = sum(1 for f in futures if f.result())

        # Require majority for success (quorum)
        quorum = (self.replication_factor // 2) + 1

        if successes >= quorum:
            return True
        else:
            raise Exception(f"Write failed: only {successes}/{self.replication_factor} succeeded")

    def read(self, key):
        """
        Read from multiple nodes, return most recent

        Handles node failures gracefully
        """
        target_nodes = self._pick_nodes(key, self.replication_factor)

        # Read from all
        values = []
        for node in target_nodes:
            try:
                value = node.read(key)
                values.append(value)
            except Exception:
                # Node failed, skip it
                continue

        if not values:
            raise Exception("All replicas failed!")

        # Return most recent (highest version)
        return max(values, key=lambda v: v['version'])

2. Checkpointing (Save Progress)

class CheckpointedTraining:
    """
    Save training progress periodically

    If crash, resume from last checkpoint
    """

    def __init__(self, model, checkpoint_dir, checkpoint_every=1000):
        self.model = model
        self.checkpoint_dir = checkpoint_dir
        self.checkpoint_every = checkpoint_every
        self.global_step = 0

    def train(self, data_loader):
        """Train with checkpointing"""
        # Try to resume from checkpoint
        self.global_step = self._load_checkpoint()

        for batch in data_loader:
            # Skip batches we've already processed
            if self.global_step < batch.id:
                continue

            # Training step
            loss = self.model.train_step(batch)
            self.global_step += 1

            # Checkpoint periodically
            if self.global_step % self.checkpoint_every == 0:
                self._save_checkpoint()
                print(f"✓ Checkpoint saved at step {self.global_step}")

    def _save_checkpoint(self):
        """Save model + training state"""
        import torch

        checkpoint = {
            'model_state': self.model.state_dict(),
            'global_step': self.global_step,
            'timestamp': time.time()
        }

        path = f"{self.checkpoint_dir}/ckpt-{self.global_step}.pt"
        torch.save(checkpoint, path)

    def _load_checkpoint(self):
        """Load latest checkpoint if exists"""
        import glob
        import torch

        checkpoints = glob.glob(f"{self.checkpoint_dir}/ckpt-*.pt")

        if not checkpoints:
            return 0

        # Load latest
        latest = max(checkpoints, key=lambda p: int(p.split('-')[1].split('.')[0]))
        checkpoint = torch.load(latest)

        self.model.load_state_dict(checkpoint['model_state'])
        print(f"✓ Resumed from step {checkpoint['global_step']}")

        return checkpoint['global_step']

3. Circuit Breaker (Prevent Cascading Failures)

class CircuitBreaker:
    """
    Prevent cascading failures

    If service keeps failing, stop calling it (open circuit)
    Give it time to recover, then try again
    """

    def __init__(self, failure_threshold=5, timeout=60):
        self.failure_threshold = failure_threshold
        self.timeout = timeout
        self.failures = 0
        self.state = 'closed'  # closed, open, half_open
        self.last_failure_time = 0

    def call(self, func, *args, **kwargs):
        """
        Call function with circuit breaker protection
        """
        import time
        # Check if circuit is open
        if self.state == 'open':
            # Check if timeout passed
            if time.time() - self.last_failure_time > self.timeout:
                self.state = 'half_open'
                print("🔄 Circuit half-open, trying again...")
            else:
                raise Exception("Circuit breaker OPEN - service unavailable")

        # Try the call
        try:
            result = func(*args, **kwargs)

            # Success! Reset if we were half-open
            if self.state == 'half_open':
                self.state = 'closed'
                self.failures = 0
                print("✓ Circuit closed - service recovered")

            return result

        except Exception as e:
            # Failure
            self.failures += 1
            self.last_failure_time = time.time()

            # Open circuit if too many failures
            if self.failures >= self.failure_threshold:
                self.state = 'open'
                print(f"⚠️ Circuit breaker OPEN after {self.failures} failures")

            raise e

# Example usage
circuit_breaker = CircuitBreaker(failure_threshold=3, timeout=30)

def call_unreliable_service(data):
    """This service sometimes fails"""
    import random
    if random.random() < 0.5:
        raise Exception("Service failed!")
    return "Success"

# Try calling with circuit breaker
for i in range(10):
    try:
        result = circuit_breaker.call(call_unreliable_service, "data")
        print(f"Request {i}: {result}")
    except Exception as e:
        print(f"Request {i}: {e}")

    time.sleep(1)

---

Consistency Models

Strong Consistency

Guarantee: All reads see the most recent write

class StronglyConsistentStore:
    """
    Every read returns the latest write

    Achieved by: Single master, synchronous replication
    """

    def __init__(self):
        self.master = {}  # Single source of truth
        self.replicas = [{}, {}]  # Read replicas
        self.version = 0

    def write(self, key, value):
        """
        Write to master, then synchronously replicate

        Slow but consistent!
        """
        # Update version
        self.version += 1

        # Write to master
        self.master[key] = {'value': value, 'version': self.version}

        # Synchronously replicate to all replicas
        for replica in self.replicas:
            replica[key] = {'value': value, 'version': self.version}

        # Only return after all replicas updated
        print(f"✓ Write {key}={value} replicated to all")

    def read(self, key):
        """
        Read from master (always latest)
        """
        return self.master.get(key, {}).get('value')

Pros: Simple to reason about Cons: Slow (sync replication), single point of failure

Eventual Consistency

Guarantee: Reads eventually see the latest write (but not immediately)

class EventuallyConsistentStore:
    """
    Reads may see stale data temporarily

    Achieved by: Asynchronous replication
    """

    def __init__(self):
        self.replicas = [{}, {}, {}]
        self.version = 0

    def write(self, key, value):
        """
        Write to one replica, asynchronously propagate

        Fast but eventually consistent
        """
        self.version += 1

        # Write to first replica immediately
        self.replicas[0][key] = {'value': value, 'version': self.version}

        # Asynchronously replicate to others
        import threading
        for replica in self.replicas[1:]:
            thread = threading.Thread(
                target=self._async_replicate,
                args=(replica, key, value, self.version)
            )
            thread.start()

        # Return immediately (don't wait for replication)
        return "OK"

    def _async_replicate(self, replica, key, value, version):
        """Replicate asynchronously"""
        import time
        time.sleep(0.1)  # Simulate network delay
        replica[key] = {'value': value, 'version': version}

    def read(self, key):
        """
        Read from random replica

        May return stale data if replication not complete!
        """
        import random
        replica = random.choice(self.replicas)
        return replica.get(key, {}).get('value')

Pros: Fast, highly available Cons: Can read stale data temporarily

For ML systems:

• Model weights: Eventual consistency OK (small staleness acceptable)
• Feature store: Strong consistency for critical features
• Predictions: No consistency needed (stateless)

---

Consensus Algorithms

Problem: How do multiple nodes agree on a value when some might fail?

Example: Leader election - which node should be the master?

Understanding the Challenge

Scenario: 3 nodes need to elect a leader

Node A thinks: "I should be leader!"
Node B thinks: "No, I should be leader!"
Node C crashes before voting

Challenge:
- Network delays mean messages arrive out of order
- Nodes might fail mid-process
- Must guarantee exactly ONE leader elected

This is the consensus problem!

Raft Algorithm (Simplified)

Raft is easier to understand than Paxos, achieving the same goal.

Key concepts:

1. States: Each node is in one of three states:
   • Follower: Accepts commands from leader
   • Candidate: Trying to become leader
   • Leader: Sends commands to followers
2. Terms: Time divided into terms (like presidencies)
   • Each term has at most one leader
   • Term number increases after each election
3. Election process:

class RaftNode:
    """
    Simplified Raft consensus node

    Real implementation is more complex!
    """

    def __init__(self, node_id, peers):
        self.node_id = node_id
        self.peers = peers
        self.state = 'follower'
        self.current_term = 0
        self.voted_for = None
        import random, time
        self.election_timeout = random.uniform(150, 300)  # ms
        self.last_heartbeat = time.time()

    def start_election(self):
        """
        Become candidate and request votes

        Called when election timeout expires without hearing from leader
        """
        # Increment term
        self.current_term += 1
        self.state = 'candidate'
        self.voted_for = self.node_id  # Vote for self

        print(f"Node {self.node_id}: Starting election for term {self.current_term}")

        # Request votes from all peers
        votes_received = 1  # Self vote

        for peer in self.peers:
            if self._request_vote(peer):
                votes_received += 1

        # Check if won election (majority)
        majority = (len(self.peers) + 1) // 2 + 1

        if votes_received >= majority:
            self._become_leader()
        else:
            # Lost election, revert to follower
            self.state = 'follower'

    def _request_vote(self, peer):
        """
        Request vote from peer

        Peer grants vote if:
        - Haven't voted in this term yet
        - Candidate's log is at least as up-to-date
        """
        request = {
            'term': self.current_term,
            'candidate_id': self.node_id
        }

        response = peer.handle_vote_request(request)

        return response.get('vote_granted', False)

    def _become_leader(self):
        """
        Become leader for this term

        Start sending heartbeats to maintain leadership
        """
        self.state = 'leader'
        print(f"Node {self.node_id}: Became leader for term {self.current_term}")

        # Send heartbeats to all followers
        self._send_heartbeats()

    def _send_heartbeats(self):
        """
        Send periodic heartbeats to prevent new elections

        Leader must send heartbeats < election_timeout
        """
        import time
        while self.state == 'leader':
            for peer in self.peers:
                peer.receive_heartbeat({
                    'term': self.current_term,
                    'leader_id': self.node_id
                })

            time.sleep(0.05)  # 50ms heartbeat interval

    def receive_heartbeat(self, message):
        """
        Receive heartbeat from leader

        Reset election timeout
        """
        # Check term
        if message['term'] >= self.current_term:
            self.current_term = message['term']
            self.state = 'follower'
            self.last_heartbeat = time.time()
            # Reset election timeout

        return {'success': True}

    def handle_vote_request(self, request):
        """
        Handle vote request from candidate

        Grant vote if haven't voted in this term yet
        """
        # Check term
        if request['term'] < self.current_term:
            return {'vote_granted': False}

        # Check if already voted
        if self.voted_for is None or self.voted_for == request['candidate_id']:
            self.voted_for = request['candidate_id']
            self.current_term = request['term']
            return {'vote_granted': True}

        return {'vote_granted': False}

Why this works:

1. Split votes: If multiple candidates, may get no majority → retry
2. Random timeouts: Reduces likelihood of split votes
3. Term numbers: Ensures old messages ignored
4. Majority requirement: Ensures at most one leader per term

Use in ML systems:

• Distributed training: Elect master node
• Model serving: Elect coordinator for A/B test assignments
• Feature store: Elect primary for writes

---

Data Partitioning Strategies

Problem: Training data is 10TB. Can’t fit on one machine!

Solution: Partition (shard) across multiple machines.

Strategy 1: Range Partitioning

Idea: Split data by key ranges

User IDs: 0 - 1,000,000

Partition 1: Users 0 - 250,000
Partition 2: Users 250,001 - 500,000
Partition 3: Users 500,001 - 750,000
Partition 4: Users 750,001 - 1,000,000

Pros: Simple, range queries efficient Cons: Hotspots if data skewed

Example:

class RangePartitioner:
    """
    Partition data by key ranges
    """

    def __init__(self, partitions):
        self.partitions = partitions  # [(0, 250000, node1), (250001, 500000, node2), ...]

    def get_partition(self, key):
        """
        Find which partition handles this key
        """
        for start, end, node in self.partitions:
            if start <= key <= end:
                return node

        raise ValueError(f"Key {key} not in any partition")

    def write(self, key, value):
        """Write to appropriate partition"""
        node = self.get_partition(key)
        node.write(key, value)

    def read(self, key):
        """Read from appropriate partition"""
        node = self.get_partition(key)
        return node.read(key)

# Usage
partitioner = RangePartitioner([
    (0, 250000, node1),
    (250001, 500000, node2),
    (500001, 750000, node3),
    (750001, 1000000, node4)
])

# Write user data
partitioner.write(user_id=123456, value={'name': 'Alice', ...})

# Read user data
user_data = partitioner.read(user_id=123456)

Hotspot problem:

If most users have IDs 0-100,000:
  Partition 1: Overloaded! 📈
  Partition 2-4: Idle 💤

Unbalanced load!

Strategy 2: Hash Partitioning

Idea: Hash key, use hash to determine partition

key → hash(key) → partition

Example:
user_id = 123456
hash(123456) = 42
partition = 42 % 4 = 2
→ Send to Partition 2

Pros: Even distribution (no hotspots) Cons: Range queries impossible

class HashPartitioner:
    """
    Partition data by hash of key
    """

    def __init__(self, nodes):
        self.nodes = nodes
        self.num_nodes = len(nodes)

    def get_partition(self, key):
        """
        Hash key to determine partition
        """
        # Hash key
        hash_value = hash(key)

        # Modulo to get partition index
        partition_idx = hash_value % self.num_nodes

        return self.nodes[partition_idx]

    def write(self, key, value):
        node = self.get_partition(key)
        node.write(key, value)

    def read(self, key):
        node = self.get_partition(key)
        return node.read(key)

# Usage
partitioner = HashPartitioner([node1, node2, node3, node4])

# Even distribution!
partitioner.write(1, 'data1')     # node2
partitioner.write(2, 'data2')     # node4
partitioner.write(3, 'data3')     # node1
partitioner.write(123456, 'data') # node2

Problem with adding/removing nodes:

With 4 nodes: hash(key) % 4 = 2 → node2
Add node5 (now 5 nodes): hash(key) % 5 = 4 → node5

All keys need remapping! 😱
Expensive!

Strategy 3: Consistent Hashing

Idea: Minimize remapping when adding/removing nodes

How it works:

1. Hash both keys and nodes to same space (e.g., 0-360°)
2. Place nodes on circle
3. Key goes to next node clockwise

Circle (0-360°):
         0°
         |
    Node B (45°)
         |
    Node C (120°)
         |
    Node D (200°)
         |
    Node A (290°)
         |
       360° (= 0°)

Key x hashes to 100° → Goes to Node C (next clockwise at 120°)
Key y hashes to 250° → Goes to Node A (next clockwise at 290°)

Add Node E at 160°:
- Only keys between 120° and 160° move from C to E
- All other keys unchanged!

import bisect

class ConsistentHashRing:
    """
    Consistent hashing for minimal remapping
    """

    def __init__(self, nodes, virtual_nodes=150):
        self.virtual_nodes = virtual_nodes
        self.ring = []
        self.node_map = {}

        for node in nodes:
            self._add_node(node)

    def _add_node(self, node):
        """
        Add node to ring with multiple virtual nodes

        Virtual nodes for better distribution
        """
        for i in range(self.virtual_nodes):
            # Hash node + replica number
            virtual_key = f"{node.id}-{i}"
            hash_value = hash(virtual_key) % (2**32)

            # Insert into sorted ring
            bisect.insort(self.ring, hash_value)
            self.node_map[hash_value] = node

    def get_node(self, key):
        """
        Find node for key

        O(log N) lookup using binary search
        """
        # Hash key
        hash_value = hash(key) % (2**32)

        # Find next node clockwise
        idx = bisect.bisect_right(self.ring, hash_value)

        if idx == len(self.ring):
            idx = 0  # Wrap around

        ring_position = self.ring[idx]
        return self.node_map[ring_position]

    def add_node(self, node):
        """
        Add new node

        Only ~1/N keys need remapping!
        """
        self._add_node(node)
        print(f"Added {node.id}, only ~{100/len(self.ring)*self.virtual_nodes:.1f}% keys remapped")

    def remove_node(self, node):
        """Remove node from ring"""
        for i in range(self.virtual_nodes):
            virtual_key = f"{node.id}-{i}"
            hash_value = hash(virtual_key) % (2**32)

            idx = self.ring.index(hash_value)
            del self.ring[idx]
            del self.node_map[hash_value]

# Usage
ring = ConsistentHashRing([node1, node2, node3, node4])

# Keys distributed evenly
key1_node = ring.get_node('user_123')
key2_node = ring.get_node('user_456')

# Add node - minimal disruption!
ring.add_node(node5)

Use in ML:

• Feature store: Partition features by entity ID
• Training data: Distribute examples across workers
• Model serving: Distribute prediction requests

---

Real-World Case Study: Netflix Recommendation System

Architecture

┌───────────────────────────────────────────────────────────┐
│                    Global Load Balancer                    │
│                         (GeoDNS)                           │
└───────────────┬───────────────────────────────────────────┘
                │
    ┌───────────┼───────────┐
    ▼           ▼           ▼
┌────────┐ ┌────────┐ ┌────────┐
│  US     │ │  EU    │ │ APAC   │  ← Regional clusters
│ Region  │ │ Region │ │ Region │
└────┬───┘ └────┬───┘ └────┬───┘
     │          │          │
     ▼          ▼          ▼
┌─────────────────────────────┐
│   Cassandra (User Profiles) │  ← Distributed database
│   Replicated across regions │
└─────────────────────────────┘
     │
     ▼
┌─────────────────────────────┐
│  Recommendation Service     │  ← 1000s of instances
│  (Load balanced)            │
└──────┬──────────────────────┘
       │
   ┌───┴────┐
   ▼        ▼
┌─────┐  ┌─────┐
│Cache│  │Model│  ← Redis cache + Model replicas
│Redis│  │Serve│
└─────┘  └─────┘

Key Distributed Systems Principles Used

1. Geographic distribution: Users routed to nearest region (low latency)
2. Replication: User data replicated across 3 regions (high availability)
3. Caching: Hot recommendations cached (reduce compute)
4. Load balancing: Requests distributed across 1000s of servers
5. Eventual consistency: Viewing history can be slightly stale
6. Partitioning: Users partitioned by user_id (horizontal scaling)

Numbers

• 200M+ users
• 1B+ recommendation requests/day
• 3 regions (US, EU, APAC)
• 1000s of servers per region
• < 100ms p99 latency for recommendations

How they handle failure:

• Region failure: Route traffic to other regions
• Server failure: Load balancer removes from pool
• Cache miss: Fall back to model inference
• Database failure: Serve stale data from replica

---

Key Takeaways

✅ Horizontal scaling - Add machines, not bigger machines
✅ Replication - Multiple copies for availability
✅ Sharding - Split data for scalability
✅ Load balancing - Distribute requests evenly
✅ Fault tolerance - Design for failure, not perfection
✅ Async communication - Pub-sub for decoupling
✅ Consistency trade-offs - CP vs AP based on use case

Core principles:

1. Failures are normal - design for them
2. Network is unreliable - use retries, timeouts
3. Consistency costs performance - choose wisely
4. Monitoring is essential - you can’t fix what you can’t see

---

Originally published at: arunbaby.com/ml-system-design/0012-distributed-systems

If you found this helpful, consider sharing it with others who might benefit.
