Federated Learning

“If data can’t move, move the model—and design the system so the server never sees what matters.”

1. Problem Statement

Many of the most valuable datasets live on user devices:

• typed text (next-word prediction)
• voice snippets (wake word, personalization)
• photos, app usage patterns, sensor streams

But collecting raw data centrally is often unacceptable due to:

• privacy expectations
• legal constraints (GDPR/CCPA, children’s data)
• trust and product risk
• bandwidth and battery cost

Federated Learning (FL) trains a global model by sending the model to devices, training locally, and sending only updates back.

Goal: Design a production-grade federated learning system that:

• improves model quality
• preserves privacy
• scales to millions of devices
• handles unreliable clients and skewed data
• is observable, debuggable, and safe

Thematic link for today: binary search and distributed algorithms. Federated learning is a distributed optimization algorithm under strict constraints; the engineering challenge is making that algorithm reliable at scale.

---

2. Understanding the Requirements

2.1 Functional requirements

• Train a global model over many client datasets without centralizing raw data.
• Periodically produce a new model version for serving (on-device or server-side).
• Support multiple model types:
  • logistic regression / small neural nets
  • large embeddings
  • speech models (acoustic / personalization heads)
• Support experimentation: A/B testing between FL variants (FedAvg vs FedProx, compression choices, DP).

2.2 Non-functional requirements (the real difficulty)

• Privacy: server should not learn individual client examples (or even individual client updates, ideally).
• Scalability: millions of eligible devices; only a fraction participate per round.
• Reliability: client dropouts are normal. Devices sleep, go offline, change networks.
• Heterogeneity: devices differ in CPU/GPU/NPU, memory, battery, OS version.
• Data skew (non-IID): one user types “football”, another types “biology”. Local distributions differ drastically.
• Security: malicious clients can poison updates or try to infer other clients.
• Observability: you need metrics without raw data; debugging is harder than centralized training.
• Cost: bandwidth, device compute, server aggregation capacity.

---

3. High-Level Architecture

At a high level, an FL system runs repeated rounds:

1. select clients
2. broadcast model + training plan
3. local training on-device
4. upload updates
5. secure aggregation
6. server optimization step
7. evaluate and promote model

3.1 Architecture diagram (control + data plane)

                    +----------------------------------+
                    |        FL Orchestrator           |
                    | (round scheduler + policy engine)|
                    +-------------------+--------------+
                                        |
                     (model + plan)     |    (eligibility + sampling)
                                        v
  +----------------------+     +----------------------+     +----------------------+
  | Model Registry       |     | Client Selector      |     | Privacy / Security   |
  | (versions, metadata) |     | (sampling, quotas)   |     | (DP params, SA keys) |
  +----------+-----------+     +----------+-----------+     +----------+-----------+
             |                                |                          |
             |                                |                          |
             v                                v                          v
    +-------------------+           +-------------------+        +-------------------+
    | Broadcast Service |---------> |  Devices (clients)|------> | Secure Aggregator |
    | (CDN / gRPC)      |  model+   | local train,      | updates| (no raw updates)  |
    +-------------------+  plan     | clip/noise,       |        +---------+---------+
                                     | upload partials   |                  |
                                     +---------+---------+                  |
                                               |                            |
                                               v                            v
                                       +-------------------+      +-------------------+
                                       | Telemetry         |      | Server Optimizer  |
                                       | (metrics only)    |      | (FedAvg/FedOpt)   |
                                       +-------------------+      +---------+---------+
                                                                         |
                                                                         v
                                                                 +-------------------+
                                                                 | Eval + Promotion  |
                                                                 | (holdout + guard) |
                                                                 +-------------------+

3.2 Key responsibilities

• Orchestrator: defines “who participates, when, and with what constraints.”
• Client runtime: runs on-device training safely, respecting battery/network policies.
• Secure aggregation: ensures server only sees aggregated updates, not individual updates.
• Model registry: versioning, metadata, reproducibility, rollback.
• Evaluation: must work without raw client data (or with privacy-safe evaluation).

---

4. Component Deep-Dives

4.1 Client selection (sampling) and eligibility

In production, you rarely train on “all devices”. You define an eligibility policy, for example:

• device on Wi-Fi
• charging
• idle
• minimum battery %
• opted-in (consent)
• locale / language segment match
• model version compatibility (runtime can execute)

Then you sample eligible devices:

• uniform random sampling can over-represent highly active regions
• you may need stratified sampling (by geography, device class, language)

Why this matters: the sampling policy is your “data loader” in FL. If it’s biased, your model is biased.

4.2 Client training plan (what executes on device)

A “round” is typically packaged as:

• base model weights
• optimizer configuration (learning rate, epochs, batch size)
• data selection rules (which local records are included)
• privacy rules (clipping norm, DP noise, secure aggregation protocol version)

This is similar to shipping a mini training job to untrusted compute. So you need:

• strict sandboxing
• deterministic kernels where possible
• a way to revoke/break-glass if a plan misbehaves (battery drain incidents are real)

4.3 Aggregation + optimization

The canonical algorithm is FedAvg:

1. each client trains locally from (w_t) to (w_t^k)
2. server averages client deltas weighted by number of examples

[ w_{t+1} = \sum_{k \in S_t} \frac{n_k}{\sum_{j \in S_t} n_j}\; w_t^k ]

Variants:

• FedAvgM (server momentum)
• FedAdam / FedYogi (server-side adaptive optimizers)
• FedProx (adds proximal term to stabilize with non-IID data)

Choosing the right optimizer is a systems decision:

• adaptive optimizers can converge faster but may be more sensitive to client drift
• non-IID data often benefits from proximal terms or personalization layers

4.4 Secure aggregation (SA)

Even model updates can leak private information (membership inference, gradient inversion). Secure aggregation aims to ensure:

• server learns only the sum/average of updates across many clients
• individual updates remain hidden

Typical properties:

• threshold (T): aggregation succeeds only if at least (T) clients complete
• dropout tolerance: protocol must handle client dropouts without revealing individuals

Operationally:

• SA adds protocol complexity and latency
• SA affects observability (you can’t inspect individual updates)

4.5 Differential privacy (DP) and clipping

DP is often layered on top of FL:

• each client clips its update to a maximum norm (C)
• adds noise (local DP or central DP depending on threat model)

Why clipping matters:

• without clipping, a single user with extreme data can dominate the aggregate
• clipping bounds sensitivity, enabling DP guarantees

There’s a “binary search” motif here: in practice you often tune the clipping norm by searching for a value that preserves utility while controlling leakage and outliers—this becomes an iterative “search over constraints”, not unlike how we search for a partition in the median problem.

4.6 Secure aggregation protocol details (what actually happens)

Secure aggregation sounds like a single box (“the secure aggregator”), but it’s usually a multi-step protocol. A simplified view:

1. Key agreement / setup
   • Clients establish pairwise secrets (or receive public keys) for masking.
2. Masking
   • Each client creates a random mask vector (r_k).
   • Client sends shares of masks such that masks can be reconstructed only if enough clients finish.
   • The client uploads masked update: (u_k + r_k).
3. Dropout handling
   • Some clients drop out mid-round.
   • The protocol reconstructs masks for missing clients (or cancels their masks) so the final sum unmasks correctly.
4. Aggregation
   • Server ends with (\sum_k u_k) (or weighted sum), but never sees any individual (u_k).

Design implications:

• You need a threshold (e.g., 1k clients) to reduce privacy leakage and to make SA feasible.
• You need a protocol state store (often a database) to track which clients completed which phase.
• SA can become your biggest source of operational failures (timeouts, key exchange bugs, state corruption).

4.7 Robust aggregation (Byzantine resilience)

Even with privacy, you still need robustness. Some clients may be buggy or malicious. Robust aggregators attempt to reduce the impact of outliers:

• Trimmed mean: drop top/bottom (p\%) per coordinate.
• Coordinate-wise median: median per coordinate (very robust, but can be noisy in high dimensions).
• Norm bounding: reject aggregates if norm spikes beyond historical ranges.

Trade-off table:

Aggregator	Pros	Cons	When to use
FedAvg	simple, fast	sensitive to outliers	trusted clients, small cohorts
Trimmed mean	robust to outliers	loses signal if trimming too aggressive	noisy client populations
Median	strong robustness	can slow convergence	high poisoning risk

4.8 DP accounting (epsilon budgets) in practice

DP is not “add noise once and forget”. You need a privacy accountant to track privacy loss across rounds.

Operationally this means:

• per model / per cohort DP budget (e.g., “this model can spend (\epsilon \le 3) over 30 days”)
• round-level parameters: clip norm, noise multiplier, cohort size
• stopping criteria: “stop training when budget is exhausted”

The practical system design question:

Where does the DP accounting live, and how do you enforce it so teams can’t silently ship a ‘privacy-unsafe’ training plan?

Good answer:

• DP accounting is part of the orchestrator policy engine
• training plans are validated before launch
• model registry stores DP metadata (noise, clip, epsilon consumed)

---

5. Data Flow (One Round End-to-End)

5.1 Step-by-step

1. Round start
   • Orchestrator decides: model v123, plan p77, cohort: “English-US”, target: 50k clients.
2. Client selection
   • Selector samples from eligible clients, respecting quotas.
3. Broadcast
   • Devices fetch:
     • model weights (CDN)
     • training plan (gRPC / config service)
4. Local training
   • Device trains for a small number of steps/epochs.
   • Applies clipping and optional noise.
5. Upload
   • Device uploads masked update shares for SA (or direct update if SA disabled).
6. Secure aggregation
   • Aggregator reconstructs only the sum/average update once threshold reached.
7. Server update
   • Server optimizer applies aggregated update to produce new model candidate v124-candidate.
8. Evaluation
   • Evaluate on:
     • server-side public/curated datasets
     • privacy-safe on-device eval (clients compute metrics and aggregate)
9. Promotion
   • If guardrails pass (quality + privacy + regressions), promote to v124.
   • Otherwise rollback, adjust plan, or reduce cohort.

5.2 What makes FL “different”

In centralized training, you can log:

• per-example losses
• per-batch gradients
• exact failure samples

In FL, you mostly see:

• aggregated metrics
• participation rates
• update norms distributions (sometimes)

This is why your evaluation design matters as much as your optimizer.

---

6. Scaling Strategies

6.1 Participation scaling: bandwidth and concurrency

Assume:

• model size: 20 MB
• 50k clients per round

Naively broadcasting 1 TB per round is expensive. So systems use:

• delta updates (send weight diffs between versions)
• compression (quantization, sparsification)
• CDN caching for base weights

On upload:

• each client might send 100 KB–5 MB depending on compression
• server must handle bursty uploads (thundering herd after a “charging + Wi-Fi” window)

6.2 Straggler and dropout handling

Dropouts are normal. Designs:

• set a strict round deadline; accept partial participation
• over-sample clients anticipating dropouts
• SA must tolerate dropout while preserving privacy

6.3 Dealing with non-IID data

Non-IID is the default. Techniques:

• FedProx: reduces client drift
• personalization layers: shared backbone + user-specific head
• clustered FL: group clients with similar distributions, train multiple models

This is where FL resembles distributed algorithms beyond “just average”: you’re effectively solving a global objective with local constraints and partial information.

6.4 Communication efficiency

Common approaches:

• 8-bit / 4-bit quantization of updates
• top-k sparsification (send largest gradient components)
• sketching (CountSketch-style)
• periodic averaging (clients do more local steps, fewer rounds)

Trade-off:

• more local steps reduces comms but increases drift on non-IID data

---

7. Implementation (Core Logic in Python)

This is a simplified simulation of FedAvg. In production, the core is the same conceptually, but wrapped in client runtimes, orchestration, and secure aggregation.

from dataclasses import dataclass
from typing import List, Tuple
import numpy as np


@dataclass
class ClientUpdate:
    n_examples: int
    delta: np.ndarray  # flattened weights delta


def clip_update(delta: np.ndarray, clip_norm: float) -> np.ndarray:
    """L2 clip to bound sensitivity and reduce outliers."""
    norm = np.linalg.norm(delta)
    if norm <= clip_norm or norm == 0.0:
        return delta
    return delta * (clip_norm / norm)


def client_train_step(w: np.ndarray, data: Tuple[np.ndarray, np.ndarray]) -> ClientUpdate:
    """
    Toy local training:
    - pretend we run a couple of SGD steps and return a model delta
    """
    x, y = data
    # Fake gradient: (this is placeholder logic for illustration)
    grad = x.T @ (x @ w - y) / max(1, len(y))
    lr = 0.1
    w_new = w - lr * grad
    delta = w_new - w
    return ClientUpdate(n_examples=len(y), delta=delta)


def fedavg_aggregate(updates: List[ClientUpdate]) -> np.ndarray:
    """Weighted average of deltas."""
    total = sum(u.n_examples for u in updates)
    if total == 0:
        raise ValueError("No examples aggregated")
    return sum((u.n_examples / total) * u.delta for u in updates)


def federated_round(w: np.ndarray, client_datas: List[Tuple[np.ndarray, np.ndarray]], clip_norm: float) -> np.ndarray:
    """One round: local train -> clip -> aggregate."""
    updates = []
    for data in client_datas:
        upd = client_train_step(w, data)
        upd.delta = clip_update(upd.delta, clip_norm)
        updates.append(upd)
    agg_delta = fedavg_aggregate(updates)
    return w + agg_delta

What’s missing (intentionally) compared to real FL:

• secure aggregation (so the server never sees upd.delta)
• device eligibility and scheduling
• privacy noise (DP)
• anti-poisoning defenses
• robust aggregation (median/trimmed mean)

Those missing pieces are the “system design interview”.

---

8. Monitoring & Metrics

You need metrics in four buckets:

8.1 Participation health

• eligible devices / selected devices / completed devices
• dropout rate by stage (download, train, upload)
• round latency distribution
• SA threshold success rate

8.2 Model update health (privacy-aware)

• aggregate update norm
• per-layer norm summaries (aggregated)
• fraction of updates clipped (clients can report “clipped yes/no” as a bit; aggregate counts)
• divergence signals (server loss spikes)

8.3 Quality metrics

• on-device eval accuracy (aggregated)
• server-side eval (public dataset) accuracy
• segment metrics (locale, device class)

8.4 Cost metrics

• bytes downloaded/uploaded per successful client
• device compute time per round
• server CPU time per aggregation

Key challenge: you must learn to debug using distributions and aggregates, not individual samples.

8.5 Debugging playbook (what you do when quality drops)

When a centralized model regresses, you can often:

• inspect failed examples
• run slice analysis on raw data
• re-train with a cleaned dataset

In FL, the playbook is different. A practical incident response flow:

1. Check participation first
   • Did eligible devices drop (OS update, policy bug, backend outage)?
   • Did completion rate change (network conditions, app crash)?
2. Check update health
   • Did aggregate update norm spike or collapse?
   • Did clipping rate jump (indicating outliers or plan misconfiguration)?
3. Check segment shifts
   • Did the sampling distribution change (more low-end devices, different geos)?
   • Are regressions concentrated in one locale/device segment?
4. Check plan drift
   • Did someone change local epochs / learning rate / batch size?
   • Did the DP policy change (more noise, smaller cohorts)?
5. Roll back safely
   • FL systems should support rollback to last-known-good model + plan.
   • Never “debug in production” by shipping risky plans to all devices.

This is why model registry metadata and orchestration policies are first-class engineering.

8.6 Privacy-safe evaluation patterns

To measure quality without collecting raw client data:

• run a local eval on device (loss/accuracy on a held-out local slice)
• report only aggregated metrics (SA and/or DP)

Common design:

• the orchestrator ships an “eval-only plan” (no training)
• devices compute metrics and upload only counts/sums
• you can then compare cohorts without seeing a single example

This becomes a reusable system primitive (“federated eval”) that product teams can use.

8.7 Fleet health metrics (client runtime as a distributed system)

Treat the client runtime like a large distributed compute cluster. You need SRE-style metrics:

• crash rate during training (by device model/OS)
• battery impact distributions
• CPU time / memory usage
• network bytes and failure codes

The “training plan” is effectively code you deploy to that cluster. So you need:

• canarying
• staged rollout
• rapid disable switches

8.8 Auditability and compliance

If FL is used for privacy reasons, you must be able to prove:

• which models were trained with which privacy parameters
• which cohorts were eligible/participating
• what DP budget was consumed over time

Operationally:

• store DP metadata in the model registry
• sign training plans (policy enforcement)
• create an audit trail of promotion decisions

---

9. Failure Modes (and Mitigations)

9.1 Client poisoning

Attack: a malicious client sends a crafted update to cause targeted behavior.

Mitigations:

• robust aggregation (trimmed mean, coordinate-wise median)
• anomaly detection on update norms (client-side + aggregate)
• limit per-client contribution via clipping
• attestations / trusted execution where possible

9.2 Privacy leakage via updates

Attack: gradient inversion or membership inference.

Mitigations:

• secure aggregation + minimum cohort size
• clipping + DP noise
• restrict model capacity for sensitive tasks

9.3 Non-IID drift and catastrophic regressions

Example: model overfits heavy users in one locale.

Mitigations:

• stratified sampling
• segment-based guardrails
• personalization layers rather than fully global updates

9.4 Operational instability

• SA failures due to too many dropouts
• app version fragmentation breaks client runtime

Mitigations:

• over-sample, shorten round deadlines
• strict compatibility checks
• staged rollouts for new plan versions

9.5 Data poisoning without “malice” (bugs look like attacks)

Not all bad updates are adversarial. Many incidents are plain bugs:

• a client preprocessing change flips labels
• a corrupted local cache creates nonsense examples
• a new OS version changes tokenizer behavior

In centralized training you might detect this via offline data validation. In FL you must rely on:

• plan versioning (so you can pinpoint which plan produced the regression)
• participation segmentation (so you can isolate which app/OS version is problematic)
• aggregate anomaly detection (norm spikes, sudden loss changes)

This is one reason why FL orchestration feels like operating a distributed system: the client fleet is not homogeneous, and “bad actors” often appear accidentally.

9.6 Silent sampling bias (the most common real-world failure)

Even if your training algorithm is perfect, your sampling can drift:

• you accidentally prefer devices that are always on Wi‑Fi and charging (a specific demographic)
• you exclude low-end phones due to memory limits (hurts global fairness)
• you oversample one geography because of timezone scheduling

Mitigations:

• explicit stratified quotas (by geo, device class, app version)
• sampling audits (“who participated last week vs target distribution?”)
• fairness guardrails (segment metrics must not regress)

If you want to impress in interviews, say:

In FL, the client selector is your data loader. Sampling bias is a training bug.

---

10. Real-World Case Study

10.1 Google Gboard next-word prediction

One of the most cited FL deployments. The model trains on-device on typed text without uploading raw keystrokes.

Key lessons:

• device scheduling is as important as the optimizer
• evaluation is hard without raw data
• privacy constraints force different debugging techniques

10.2 Apple on-device personalization

Apple has publicly discussed privacy-preserving analytics and on-device ML patterns. Even when not strictly FL, the constraints are similar:

• data stays on device
• server learns via aggregates

10.3 A speech-flavored case study (personalized wake words / accents)

Speech is a great “stress test” for FL:

• client data is extremely sensitive
• models are large
• non-IID is strong (accent, environment, microphone)

A realistic production approach:

• keep the base wake word detector global and stable
• personalize a small threshold or adapter layer per device
• aggregate only privacy-protected signals across devices to improve the global model slowly

Engineering lesson: you often split learning into:

• fast local personalization (small, device-specific)
• slow global improvements (federated, heavily gated)

This reduces risk while still benefiting from collective learning.

---

11. Cost Analysis

Cost drivers:

• bandwidth (download + upload)
• server aggregation (compute + storage for protocol states)
• engineering complexity (privacy/security requirements increase operational overhead)

Practical levers:

• compress models and updates
• reduce round frequency (but monitor for quality stagnation)
• select only clients likely to complete (charging + Wi-Fi windows)

11.1 A back-of-the-envelope cost model (so you can reason in interviews)

Assume a mid-size on-device model:

• model weights: 20 MB (download)
• update payload (compressed): 200 KB (upload)
• 50k participating clients per day (across many rounds)

Daily bandwidth:

• downloads: (50{,}000 \times 20\text{MB} = 1{,}000{,}000\text{MB} \approx 1\text{TB})
• uploads: (50{,}000 \times 200\text{KB} = 10{,}000{,}000\text{KB} \approx 10\text{GB})

Even if CDNs make downloads “cheap”, 1 TB/day is not free. This is why production FL systems invest in:

• delta updates between model versions
• caching via CDN
• smaller adapter-based updates rather than full model updates

11.2 The “client compute cost” you don’t pay (but your users do)

Server-side training costs show up on your cloud bill. Federated training moves a large part of compute to devices:

• CPU/NPU cycles
• battery usage
• thermal constraints

If training is too aggressive, you get:

• user complaints (“phone gets hot”)
• OS throttling
• drops in completion rate (which also hurts model quality)

So cost is not just “dollars”; it’s:

• product risk
• engagement risk
• fleet health risk

11.3 ROI framing

In many teams, FL is justified when:

• privacy constraints block centralized data collection
• personalization materially improves retention/engagement
• the incremental engineering effort pays off via model quality and trust

In interviews, a crisp way to say it:

FL is expensive to build, but sometimes it’s the only path to high-quality models under privacy constraints.

---

12. Key Takeaways

1. Federated learning is distributed optimization under constraints: unreliable clients, non-IID data, privacy/security.
2. System design dominates: client eligibility, secure aggregation, privacy, observability, and rollout safety are the hard parts.
3. Boundary-first thinking scales: like the median partition trick, FL often succeeds by optimizing what you exchange (bounded, aggregated signals) rather than moving raw data.

12.1 A concise “design review checklist” for FL systems

If you’re reviewing a federated learning design, ask:

• Client policy
  • How do we decide eligibility (Wi‑Fi, charging, opt-in)?
  • What is the target sampling distribution (and how do we audit it)?
• Privacy
  • Is secure aggregation enabled for sensitive models?
  • Do we clip updates? Where is the DP budget accounted and enforced?
  • What is the minimum cohort size per segment?
• Robustness
  • What aggregator do we use (FedAvg vs robust variants)?
  • How do we handle dropouts and stragglers?
  • What anti-poisoning mitigations exist?
• MLOps
  • Are plans versioned and validated before execution?
  • Can we canary/roll back both model and plan quickly?
  • What metrics exist without inspecting raw client data?

If these questions have crisp answers, you’re operating FL like a real distributed system instead of a research prototype.

12.2 Deployment note: FL still needs a serving story

Federated learning updates a model, but product impact comes from serving:

• on-device inference (TFLite/CoreML)
• server-side inference (if the model isn’t privacy-sensitive at query time)

Practical serving considerations:

• keep runtime compatibility (model format + ops supported on older devices)
• stage rollouts with kill-switches (bad models are user-facing incidents)
• monitor on-device latency and battery impact (quality gains can be negated by UX regressions)

In other words: FL is not just training infrastructure; it’s an end-to-end system from “round” to “release”.

---

Originally published at: arunbaby.com/ml-system-design/0051-federated-learning

If you found this helpful, consider sharing it with others who might benefit.
