Anomaly Detection

“Anomaly detection is trapping rain water for metrics: find the boundaries of ‘normal’ and measure what overflows.”

1. Problem Statement

In production ML and data systems, anomalies are the early warning signals of:

• data quality regressions
• pipeline failures
• model performance drift
• fraud and abuse
• infrastructure incidents

The goal is to design an anomaly detection system that:

• ingests high-volume metrics/events
• detects meaningful anomalies quickly
• keeps false positives low (alert fatigue is real)
• supports investigation and root cause analysis
• is robust to seasonality and shifting baselines

Today’s shared theme is pattern recognition: in DSA, we detect the “boundary pattern” that determines trapped water. In anomaly detection, we detect deviations from the learned “normal pattern”.

---

2. Understanding the Requirements

2.1 Functional requirements

• Inputs
• time-series metrics (QPS, latency, error rates)
• categorical counts (events by user type, country)
• distributions (histograms, sketches)
• model signals (loss, accuracy proxies, embedding stats)
• Outputs
• anomaly alerts with severity
• explanation context (top contributing dimensions)
• links to dashboards/runbooks
• ability to suppress/acknowledge

2.2 Non-functional requirements

• Low latency: detect within minutes (or seconds for fraud/infra).
• Scalability: multi-tenant at 1M events/sec.
• Precision: too many alerts kill trust.
• Recall: missing important anomalies is costly.
• Robustness: handle missing data, late arrivals, backfills.
• Interpretability: support “why did this alert fire?”.
• Governance: alert ownership, runbooks, on-call routing.

---

3. High-Level Architecture

3.1 Diagram

Producers (services / models / pipelines) | v +-------------+ +-------------------+ | Kafka/PubSub| -----> | Stream Processor | +-------------+ | (Flink/Spark) | | +---------+---------+ | | | v | +-------------------+ | | Feature Builder | | | (windows, joins) | | +---------+---------+ | | v v +-------------------+ +-------------------+ | TS Store | | Detector Service | | (Prom/TSDB) | | rules + ML | +---------+---------+ +---------+---------+ | | v v +-------------------+ +-------------------+ | Dashboards | | Alert Router | | (Grafana) | | (Pager/Slack) | +-------------------+ +---------+---------+ | v +-------------------+ | Case Mgmt / RCA | | (tickets, notes) | +-------------------+

3.2 Core idea

You generally run a two-layer detector:

• fast rules for clear anomalies (error rate > X, no events for Y minutes)
• statistical/ML detectors for subtle drift (seasonality-aware, multivariate)

Rules are cheap and interpretable. ML handles complex patterns, but must be deployed carefully.

---

4. Component Deep-Dives

4.1 Data ingestion and schema discipline

The most common failure is not “bad model”, it’s bad data:

• missing metrics due to instrumentation bugs
• unit changes (ms → s)
• counter resets
• duplicate events

So your system needs:

• schema registry (event contracts)
• validation (ranges, types, monotonicity for counters)
• backfill handling (late arrivals)

4.2 Feature engineering for anomaly detection

Features depend on signal type:

Time series

• moving averages, EWMA
• seasonal decomposition (daily/weekly)
• derivative and acceleration (change rates)

Categorical slices

• per-dimension rates (country, device)
• top-k contributors (heavy hitters)
• ratio metrics (errors / requests)

Distributions

• quantiles (p50/p95/p99)
• histogram distance metrics (KL divergence, Wasserstein)

This is the “pattern recognition” layer: translate raw signals into something that makes deviations obvious.

4.3 Detectors: rules, statistics, ML

Common detector families:

• Rules
• simple thresholds, rate-of-change, “no data” checks

• best for: clear SLO violations, missing pipelines

• Statistical
• z-score with robust estimators (median/MAD)
• EWMA control charts
• seasonal baselines (Holt-Winters)

• best for: stable metrics with known periodicity

• ML / Unsupervised
• Isolation Forest, One-Class SVM
• autoencoders
• clustering distance to centroids
• best for: high-dimensional signals, unknown patterns

The important production truth:

You don’t “pick one model”. You build a system that can run multiple detectors and fuse them.

4.4 Alerting and routing

Anomaly detection is useless without action. You need:

• deduplication (same alert grouped)
• suppression (maintenance windows)
• routing by ownership (service/team)
• escalation policies and runbooks

4.5 Explanation (why did this fire?)

For slice-based anomalies, a powerful technique is “top contributors”:

• overall error rate rose
• 80% of delta is from country=IN and device=android_low_end

This reduces MTTR dramatically.

4.6 Thresholding is a product decision (not just statistics)

A detector outputs a score. You still need to decide:

• when do we page a human?
• when do we log-only?
• when do we auto-mitigate?

A practical severity ladder:

• S0 (log-only): weak signal, used for trend analysis
• S1 (notify): Slack alert, no pager
• S2 (page): likely user impact or SLO breach
• S3 (auto-mitigate + page): safety-critical systems

How to set thresholds:

• start with conservative paging thresholds (avoid alert fatigue)
• use historical replay to estimate expected alert volume
• adjust per metric and per service criticality

The uncomfortable truth:

“Correct” thresholds depend on team capacity, business impact, and tolerance for noise.

4.7 Root cause analysis (RCA) requires drill-down, not just detection

Detection answers: “something is wrong”. RCA answers: “what is wrong, where, and why”.

A common production pattern:

1. detect anomaly on an aggregate metric (e.g., error_rate)
2. compute deltas by dimension to find top contributors:
   • region, cluster, device, app_version, request_type
3. present ranked suspects with evidence

This is essentially “explainability via decomposition”. It often beats fancy ML models in reducing MTTR.

4.8 Handling seasonality and holidays (the hard baseline problem)

Many metrics have:

• daily cycles (traffic peaks)
• weekly cycles (weekday vs weekend)
• event-driven spikes (launches, holidays)

If you ignore seasonality, you’ll page every day at 9am.

Baseline strategies (in increasing complexity):

• compare to “same time yesterday / last week”
• rolling window median and MAD
• Holt-Winters / Prophet-like seasonal models
• learned baselines per segment

For production, the best choice is often:

• simple seasonal comparisons + robust statistics
• plus explicit suppression windows for known events (launch windows)

---

5. Data Flow (Streaming + Batch)

5.1 Streaming path

• ingest events into Kafka
• compute rolling windows (1m, 5m, 1h)
• compute features (rates, deltas)
• run rule-based detectors for immediate signals
• run lightweight statistical detectors (EWMA)
• emit alerts

5.2 Batch path

• nightly backfills, seasonality model fitting
• compute baselines per metric and per segment
• retrain unsupervised models if used
• store parameters in a registry

This hybrid is important because:

• streaming is low-latency but limited context
• batch has rich history but higher latency

---

6. Implementation (Core Logic in Python)

The goal here is to show “detector primitives” that can be composed. In production you’d wrap these in streaming jobs and persistent state.

6.1 Robust z-score (median + MAD)

``python import numpy as np

def robust_zscore(x: np.ndarray) -> np.ndarray: “”” Robust z-score using median and MAD (median absolute deviation). Less sensitive to outliers than mean/std. “”” med = np.median(x) mad = np.median(np.abs(x - med)) + 1e-9 return 0.6745 * (x - med) / mad

def detect_anomaly_robust_z(x_window: np.ndarray, threshold: float = 4.0) -> bool: z = robust_zscore(x_window) return abs(z[-1]) >= threshold ``

6.2 EWMA control chart

``python def ewma(series: np.ndarray, alpha: float = 0.2) -> np.ndarray: out = np.zeros_like(series, dtype=float) out[0] = series[0] for i in range(1, len(series)): out[i] = alpha * series[i] + (1 - alpha) * out[i - 1] return out

def detect_ewma_shift(series: np.ndarray, alpha: float = 0.2, k: float = 3.0) -> bool: “”” Simple EWMA shift detector: compare last value to EWMA +/- k * std. (In production, use rolling std and seasonality-aware baselines.) “”” smoothed = ewma(series, alpha=alpha) mu = np.mean(smoothed[:-1]) sigma = np.std(smoothed[:-1]) + 1e-9 return abs(smoothed[-1] - mu) > k * sigma ``

6.3 Fusing detectors (rule + stats)

``python from dataclasses import dataclass

@dataclass class DetectionResult: is_anomaly: bool reason: str

def fused_detector(series: np.ndarray) -> DetectionResult: # Rule: “no data” or impossible values if np.isnan(series[-1]): return DetectionResult(True, “missing_data”) if series[-1] < 0: return DetectionResult(True, “negative_value”)

# Statistical: robust z-score if detect_anomaly_robust_z(series, threshold=4.0): return DetectionResult(True, “robust_zscore”)

# Statistical: EWMA shift if detect_ewma_shift(series, alpha=0.2, k=3.0): return DetectionResult(True, “ewma_shift”)

return DetectionResult(False, “normal”) ``

This illustrates a production principle: anomaly detection is a system of small components, not a single model.

6.4 Multivariate anomaly detection (when one metric isn’t enough)

Many real anomalies only show up when you look at multiple signals together:

• latency rises while QPS is stable (infra saturation)
• error rate rises only for one endpoint (partial outage)
• embedding stats shift while overall accuracy proxy is stable (silent drift)

Multivariate approaches:

• Isolation Forest / One-Class SVM on feature vectors
• reconstruction error from autoencoders
• clustering distance to normal centroids

Here’s a small Isolation Forest example (conceptual; production needs careful feature scaling and segment baselines):

``python from sklearn.ensemble import IsolationForest import numpy as np

def fit_isolation_forest(X: np.ndarray) -> IsolationForest: “”” X shape: [n_samples, n_features] Features could include: latency_p95, error_rate, qps, cpu, mem, etc. “”” model = IsolationForest( n_estimators=200, contamination=”auto”, random_state=0, ) model.fit(X) return model

def detect_multivariate(model: IsolationForest, x_latest: np.ndarray, score_threshold: float) -> bool: # sklearn: higher score = more normal; lower = more anomalous score = float(model.score_samples(x_latest.reshape(1, -1))[0]) return score < score_threshold ``

Operational note:

• multivariate models are powerful but harder to explain
• pair them with decomposition-style explanations (top contributor slices) for RCA
• gate paging on both “model score” and “impact metrics” (e.g., SLO risk)

---

7. Scaling Strategies

7.1 Cardinality management (the silent killer)

If you alert on metric x country x device x app_version, cardinality explodes. Strategies:

• alert only on top-K segments (heavy hitters)
• hierarchical detection:
• detect anomaly globally
• then drill down into segments to find top contributors
• sketching (Count-Min Sketch for counts, t-digest/KLL for quantiles)

7.2 State management in streaming

Detectors need history:

• rolling windows
• seasonal baselines
• suppression state

Store state in:

• stream processor state (RocksDB in Flink)
• or external state stores (Redis, Cassandra)

7.3 Multi-tenancy

Different teams want different sensitivity. You need:

• per-metric configs
• per-tenant budgets (alert quotas)
• isolation (one tenant’s high-cardinality metrics shouldn’t DOS the system)

7.4 Change-log correlation (bridging detection to action)

The fastest way to reduce MTTR is to correlate anomalies with “what changed”:

• deploys
• feature flags
• config pushes
• schema changes
• infrastructure events (autoscaling, failovers)

A pragmatic design:

• ingest change events into the same stream as metrics
• attach a “recent changes” panel to every alert
• compute correlation candidates (“this alert fired within 10 minutes of deploy X in region Y”)

This does not require fancy causality to be useful. In practice, showing the top 3 recent changes near the anomaly often saves hours.

7.5 Collective anomalies (the ones point detectors miss)

Not all anomalies are single spikes. Common anomaly types:

• point anomaly: one bad point
• contextual anomaly: normal value at the wrong time (seasonality)
• collective anomaly: a sustained subtle shift (e.g., p95 latency +5% for 6 hours)

Collective anomalies are the hardest in production because:

• they are “small enough” to evade thresholds
• but “long enough” to cause real user impact

Detectors for collective anomalies:

• EWMA / CUSUM-style change detection
• burn-rate based alerting (SLO-focused)
• rolling baseline comparisons (same time last week)

---

8. Monitoring & Metrics (for the anomaly system itself)

You need to monitor your monitor:

• alert volume per tenant
• false positive rate proxies (how many alerts are auto-acked)
• time-to-ack, time-to-resolve
• detector latency and backlog
• “missing data” alert rates (often instrumentation failures)

And you need a feedback loop: when humans label an alert as “noise”, it should improve the system.

8.1 Evaluating anomaly detection (without perfect labels)

Unlike classification, anomaly detection often lacks ground truth. Practical evaluation strategies:

• Historical replay
• replay a week/month of metrics

• compare alerts to known incidents and change logs

• Synthetic injections
• inject controlled anomalies (drop QPS, spike errors, shift distributions)

• ensure detectors catch them with acceptable delay

• Proxy labels
• incident tickets, rollbacks, on-call notes

• not perfect, but useful for measuring recall on “real pain”

• Human-in-the-loop tuning
• collect feedback (noise vs real)
• tune thresholds and suppression policies

You typically optimize for:

• high precision for paging alerts
• high recall for “notify” alerts (lower severity)

8.2 “Impact gating” (avoid paging on harmless anomalies)

A classic production trick: don’t page just because a detector score is high. Page when:

• anomaly score is high and
• impact metrics indicate user risk

Examples:

• error rate anomaly + SLO burn rate increasing
• latency anomaly + p99 above a hard threshold

This reduces alert fatigue while keeping critical incidents caught.

---

9. Failure Modes (and Mitigations)

9.1 Alert fatigue

Mitigation:

• dedupe + grouping
• severity levels
• alert budgets and rate limits
• better routing + suppression windows

9.2 Seasonality false positives

Mitigation:

• baseline models (daily/weekly)
• compare to same time last week
• use robust estimators

9.3 Missing data vs true zero

Mitigation:

• explicit “heartbeat” signals
• separate pipelines for “metric missing” vs “value is zero”

9.4 Feedback loops and gaming

If teams learn to “silence alerts”, your system loses trust. Mitigation:

• governance: who can suppress, for how long
• audit logs
• periodic review of suppressed alerts

9.5 High-cardinality explosions

A common production outage pattern:

• someone adds a new label/dimension (e.g., user_id)
• cardinality explodes
• storage and stream processing costs spike
• detectors become meaningless (each series has too few points)

Mitigations:

• enforce label allowlists/denylists
• use hierarchical detection (alert on aggregate first, then drill down)
• cap top-k dimensions and use heavy-hitter sketches
• charge back cost to teams for uncontrolled cardinality (governance matters)

9.6 “Anomaly” isn’t always “bad” (launches look like incidents)

Product launches and marketing events create legitimate shifts. If the system treats every spike as an incident, it loses credibility.

Mitigations:

• change-log correlation: if a known launch happened, adjust baseline
• planned maintenance windows (suppression)
• “expected anomaly” annotations (Grafana-style)

This is another reason anomaly detection is a system: you need metadata and governance, not just math.

---

10. Real-World Case Study

Netflix/Streaming quality

Netflix-like systems track:

• playback start failures
• buffering ratio
• CDN health

Anomalies matter because:

• small regressions affect millions of users quickly
• seasonality exists (prime time)

Common pattern:

• global anomaly triggers
• drill-down identifies region/device/CDN nodes as top contributors
• routing goes to the owning team (CDN vs player vs backend)

10.1 A second case study: data pipeline anomaly in ML training

Consider a feature pipeline that writes training data daily. One day, an upstream service changes a field from “milliseconds” to “seconds”.

What happens:

• models still train (no crash)
• loss might even look “okay”
• but downstream predictions degrade subtly

Anomaly detection can catch this early with:

• schema validation: units and ranges
• distribution shift: feature histograms vs baseline
• training metrics drift: gradient norms, embedding stats

The key lesson: the most expensive ML failures are often “silent correctness failures”. You need anomaly detection not just for infra metrics, but for data and model health signals.

10.2 An “RCA-first” UI pattern

When an alert fires, show:

• the metric that triggered
• the baseline comparison (last week, seasonal)
• the top contributing dimensions (country/device/version)
• links to relevant dashboards and runbooks
• recent change log correlation (deploys, config changes, schema changes)

This turns anomaly detection from “pager noise” into a decision system.

---

11. Cost Analysis

Cost drivers:

• stream processing state (memory/disk)
• high-cardinality storage
• alert routing and case management integration

Cost levers:

• limit cardinality and use sketches
• run heavy ML detectors only when cheaper detectors suspect an anomaly
• compress histories and store only what’s needed for RCA windows

---

12. Key Takeaways

1. Anomaly detection is a system, not a model: ingestion, features, detectors, alerting, RCA.
2. Boundaries and invariants matter: define “normal” and detect boundary violations, like two-pointer reasoning.
3. Operational success = low false positives + good explanations: otherwise no one trusts alerts.

12.1 Appendix: detector selection cheat sheet

Use this as a quick mapping from problem → detector:

Signal type	Typical anomaly	Best first detector	Notes
Counters (QPS, errors)	drop to zero, spike	rules + burn-rate	also detect missing vs true zero
Latency percentiles	sustained shift	EWMA / baseline compare	seasonality is common
High-dimensional telemetry	weird combinations	Isolation Forest / AE	require careful explanation
Categorical slices	one segment dominates	hierarchical drill-down	“top contributors” is key
Data features (ML)	distribution shift	histogram distance + rules	unit changes are common

Rule of thumb:

• page on rules + high-impact metrics
• use ML scores as supporting evidence or for “notify” tier alerts

12.2 Appendix: an alerting playbook (how to keep trust)

If your anomaly system is noisy, it dies. A practical playbook:

• Start narrow
• detect a small set of critical metrics

• keep paging volume low

• Add explainability
• top contributors
• baseline comparisons

• recent change log correlation

• Use severity tiers
• paging only for high-confidence/high-impact signals

• Slack-only for exploratory detectors

• Build feedback
• allow “noise” labeling
• review suppressed alerts periodically

This is the same “pattern recognition” lesson as the DSA problem: don’t react to every fluctuation; define the boundary of “actionable abnormal”.

12.3 Appendix: baseline modeling options (from simplest to strongest)

When teams say “anomaly detection”, they often mean “baseline modeling”. Here’s a pragmatic ladder:

• Static thresholds
• best for: hard limits (error_rate must be < 1%)

• worst for: seasonal metrics

• Rolling robust baseline (median/MAD)
• best for: noisy but mostly stationary signals

• robust to spikes and outliers

• Seasonal baseline (same time last week)
• best for: strong weekly patterns

• easy to explain and cheap to run

• Holt-Winters / ETS
• best for: smooth seasonality + trend

• good interpretability

• Learned baselines (per segment)
• best for: complex multi-segment products
• requires strong governance to avoid accidental bias

Production tip: start with seasonal comparisons + robust statistics. Only move to heavier models when simpler baselines fail.

12.4 Appendix: a minimal “config contract” for detectors

To run this system safely at scale, you need a configuration contract:

• metric name
• aggregation window (1m/5m/1h)
• baseline method
• sensitivity / threshold
• severity tier (log/notify/page)
• routing owner (team/on-call)
• suppression windows (maintenance)

This turns anomaly detection into an operable platform: teams can onboard new signals without changing code, and you can audit changes.

12.5 Appendix: anomaly vs drift vs outlier (how teams get confused)

These terms are often used interchangeably, but they’re different:

• Outlier: a single unusual point relative to its neighbors.

• Example: one batch has a huge spike in null values.

• Anomaly: a point or segment that violates an expected pattern.

• Example: error rate spike at 2am that is not part of normal seasonality.

• Drift: the underlying distribution changes over time.
• Example: feature distribution slowly shifts after a product change.

Operationally:

• outliers are often “data quality” issues
• anomalies are “incident” candidates
• drift is “model health” and requires different response (retraining, feature changes)

The best platforms support all three, but keep the response paths distinct:

• anomalies page humans
• drift triggers investigation and model iteration
• outliers often trigger data validation and pipeline fixes

12.6 Appendix: an on-call runbook for anomaly alerts

When an alert pages a human, the system should also provide a runbook-style checklist. A practical sequence:

1. Confirm impact
   • are user-facing SLOs burning?
   • is this confined to a segment (region/device) or global?
2. Check data validity
   • missing data vs real zeros
   • instrumentation changes (new labels, new units)
3. Correlate with recent changes
   • deploys, feature flags, config changes
   • schema changes in pipelines
4. Drill down
   • top contributors by dimension
   • compare against historical baselines (same time last week)
5. Mitigate
   • rollback suspect deploys
   • fail over traffic if it’s infra-related
   • suppress alerts only with an explicit maintenance annotation

This checklist turns “anomaly detection” into operational reality: consistent response beats clever scoring.

12.7 Appendix: testing detectors safely before production

Before enabling paging:

• run in shadow mode (log-only) for 1–2 weeks
• replay historical incidents and ensure alerts would have fired
• inject synthetic anomalies (spikes, drops, sustained shifts)
• check alert volume budgets per team

If you do this, you avoid the most common failure: shipping a detector that immediately pages everyone and loses trust forever.

12.8 Appendix: cost and scaling intuition (why platforms exist)

Teams often start anomaly detection as ad-hoc scripts per service. At small scale, that works. At org scale, it collapses due to:

• duplicated logic (everyone re-implements EWMA differently)
• inconsistent thresholds and alert policies
• uncontrolled cardinality costs
• lack of auditability (“who changed this threshold?”)

That’s why anomaly detection becomes a platform:

• shared ingestion and schema validation
• shared baseline modeling primitives
• shared routing/suppression/governance
• shared RCA UI patterns (top contributors, change-log correlation)

If you can explain this evolution clearly in interviews, it signals strong “systems taste”.

12.9 Appendix: multi-tenancy and fairness (an under-discussed risk)

Anomaly systems can create “fairness” issues at the org level:

• teams with noisier metrics consume disproportionate paging attention
• teams with low traffic get ignored because their signals are sparse
• some regions/devices get under-monitored because baselines are not segment-aware

Mitigations:

• per-tenant alert budgets (rate limits and quotas)
• segment-aware baselines for critical dimensions (region/device/app version)
• “coverage” metrics: which segments have enough data to monitor reliably
• explicit ownership: every alert route must map to a team/runbook

This is the same lesson as other large platforms: governance is part of the technical design.

12.10 Appendix: a minimal anomaly “triage packet” (what every alert should carry)

To make alerts actionable, every alert should include a small, standardized packet:

• What: metric name, current value, baseline value, anomaly score
• When: start time, duration, detection time
• Where: top affected segments (region/device/version) with contribution deltas
• Impact: SLO burn rate / user-impact proxy
• Why likely: top recent change events correlated (deploy/flag/config/schema)
• Next: runbook link + owning team + mitigation suggestions (rollback, failover)

This single design choice reduces MTTR more than most detector tweaks, because it turns “math output” into “operational context”.

---

Originally published at: arunbaby.com/ml-system-design/0052-anomaly-detection

If you found this helpful, consider sharing it with others who might benefit.
