How voice assistants recognize who’s speaking, the biometric authentication powering “Hey Alexa” and personalized experiences.

Introduction

Speaker Recognition is the task of identifying or verifying a person based on their voice.

Two main tasks:

  1. Speaker Identification: Who is speaking? (1:N matching)
  2. Speaker Verification: Is this person who they claim to be? (1:1 matching)

Why it matters:

  • Personalization: Voice assistants adapt to users
  • Security: Voice biometric authentication
  • Call centers: Route calls to correct agent
  • Forensics: Identify speakers in recordings

What you’ll learn:

  • Speaker embeddings (d-vectors, x-vectors)
  • Verification vs identification
  • Production deployment patterns
  • Anti-spoofing techniques
  • Real-world applications

Problem Definition

Design a speaker recognition system.

Functional Requirements

  1. Enrollment
    • Capture user’s voice samples
    • Extract speaker embedding
    • Store in database
  2. Verification
    • Given audio + claimed identity
    • Verify if speaker matches
  3. Identification
    • Given audio only
    • Identify speaker from database

Non-Functional Requirements

  1. Accuracy
    • False Acceptance Rate (FAR) < 1%
    • False Rejection Rate (FRR) < 5%
    • Equal Error Rate (EER) < 2%
  2. Latency
    • Enrollment: < 500ms
    • Verification: < 100ms
  3. Scalability
    • Support millions of enrolled speakers
    • Fast lookup in embedding space

Speaker Embeddings

Core idea: Map variable-length audio → fixed-size vector that captures speaker identity.

X-Vectors

State-of-the-art speaker embeddings using time-delay neural networks (TDNN).

import torch
import torch.nn as nn

class XVectorExtractor(nn.Module):
    """
    X-vector architecture for speaker embeddings

    Input: Variable-length audio features (mel-spectrogram)
    Output: Fixed 512-dim speaker embedding
    """

    def __init__(self, input_dim=40, embedding_dim=512):
        super().__init__()

        # Frame-level layers (TDNN)
        self.tdnn1 = nn.Conv1d(input_dim, 512, kernel_size=5, dilation=1)
        self.tdnn2 = nn.Conv1d(512, 512, kernel_size=3, dilation=2)
        self.tdnn3 = nn.Conv1d(512, 512, kernel_size=3, dilation=3)
        self.tdnn4 = nn.Conv1d(512, 512, kernel_size=1, dilation=1)
        self.tdnn5 = nn.Conv1d(512, 1500, kernel_size=1, dilation=1)

        # Statistical pooling
        # Computes mean + std over time → fixed size

        # Segment-level layers
        self.fc1 = nn.Linear(3000, 512)  # 1500 mean + 1500 std
        self.fc2 = nn.Linear(512, embedding_dim)

        self.relu = nn.ReLU()
        self.bn = nn.BatchNorm1d(512)

    def forward(self, x):
        """
        Args:
            x: (batch, time, features)  e.g., (B, T, 40)

        Returns:
            embeddings: (batch, embedding_dim)
        """
        # Transpose for Conv1d: (batch, features, time)
        x = x.transpose(1, 2)

        # Frame-level processing
        x = self.relu(self.tdnn1(x))
        x = self.relu(self.tdnn2(x))
        x = self.relu(self.tdnn3(x))
        x = self.relu(self.tdnn4(x))
        x = self.relu(self.tdnn5(x))

        # Statistical pooling: mean + std over time
        mean = torch.mean(x, dim=2)
        std = torch.std(x, dim=2)
        stats = torch.cat([mean, std], dim=1)  # (batch, 3000)

        # Segment-level processing
        x = self.relu(self.fc1(stats))
        x = self.bn(x)
        embeddings = self.fc2(x)  # (batch, embedding_dim)

        # L2 normalize
        embeddings = embeddings / torch.norm(embeddings, p=2, dim=1, keepdim=True)

        return embeddings

# Usage
model = XVectorExtractor(input_dim=40, embedding_dim=512)
model.eval()

# Extract embedding
mel_spec = torch.randn(1, 300, 40)  # 3 seconds of audio
embedding = model(mel_spec)  # (1, 512)

print(f"Embedding shape: {embedding.shape}")
print(f"Embedding norm: {torch.norm(embedding):.4f}")  # Should be ~1.0

Training Speaker Embeddings

class SpeakerEmbeddingTrainer:
    """
    Train x-vector model using cross-entropy over speaker IDs
    """

    def __init__(self, model, num_speakers, device='cuda'):
        self.model = model.to(device)
        self.device = device

        # Classification head for training
        self.classifier = nn.Linear(512, num_speakers).to(device)

        # Loss
        self.criterion = nn.CrossEntropyLoss()

        # Optimizer
        self.optimizer = torch.optim.Adam(
            list(self.model.parameters()) + list(self.classifier.parameters()),
            lr=0.001
        )

    def train_step(self, audio_features, speaker_labels):
        """
        Single training step

        Args:
            audio_features: (batch, time, features)
            speaker_labels: (batch,) integer speaker IDs

        Returns:
            Loss value
        """
        self.model.train()
        self.optimizer.zero_grad()

        # Extract embeddings
        embeddings = self.model(audio_features)

        # Classify
        logits = self.classifier(embeddings)

        # Loss
        loss = self.criterion(logits, speaker_labels)

        # Backward
        loss.backward()
        self.optimizer.step()

        return loss.item()

    def extract_embedding(self, audio_features):
        """Extract embedding for inference (no classification head)"""
        self.model.eval()

        with torch.no_grad():
            embedding = self.model(audio_features)

        return embedding

# Training loop
trainer = SpeakerEmbeddingTrainer(
    model=XVectorExtractor(),
    num_speakers=10000  # Number of speakers in training set
)

for epoch in range(100):
    for batch in train_loader:
        audio, speaker_ids = batch

        loss = trainer.train_step(audio.to(trainer.device), speaker_ids.to(trainer.device))

    print(f"Epoch {epoch}, Loss: {loss:.4f}")

Speaker Verification

Verify if two audio samples are from the same speaker.

Cosine Similarity

import numpy as np
import torch

class SpeakerVerifier:
    """
    Speaker verification system

    Uses cosine similarity between embeddings
    """

    def __init__(self, embedding_extractor, threshold=0.5):
        self.extractor = embedding_extractor
        self.threshold = threshold

    def extract_embedding(self, audio):
        """Extract embedding from audio"""
        # Preprocess audio → mel-spectrogram
        features = self._audio_to_features(audio)

        # Extract embedding (support trainer-style or raw nn.Module)
        with torch.no_grad():
            if hasattr(self.extractor, 'extract_embedding'):
                emb_tensor = self.extractor.extract_embedding(features)
            else:
                emb_tensor = self.extractor(features)

        return emb_tensor.cpu().numpy().flatten()

    def _audio_to_features(self, audio):
        """Convert audio to mel-spectrogram"""
        import librosa

        # Compute mel-spectrogram
        mel_spec = librosa.feature.melspectrogram(
            y=audio,
            sr=16000,
            n_mels=40,
            n_fft=512,
            hop_length=160
        )

        # Log scale
        mel_spec = librosa.power_to_db(mel_spec)

        # Transpose: (time, features)
        mel_spec = mel_spec.T

        # Convert to tensor
        features = torch.from_numpy(mel_spec).float().unsqueeze(0)

        return features

    def cosine_similarity(self, emb1, emb2):
        """
        Compute cosine similarity

        Returns:
            Similarity score in [-1, 1]
        """
        return np.dot(emb1, emb2) / (np.linalg.norm(emb1) * np.linalg.norm(emb2))

    def verify(self, audio1, audio2):
        """
        Verify if two audio samples are from same speaker

        Args:
            audio1, audio2: Audio waveforms

        Returns:
            {
                'is_same_speaker': bool,
                'similarity': float,
                'threshold': float
            }
        """
        # Extract embeddings
        emb1 = self.extract_embedding(audio1)
        emb2 = self.extract_embedding(audio2)

        # Compute similarity
        similarity = self.cosine_similarity(emb1, emb2)

        # Decision
        is_same = similarity >= self.threshold

        return {
            'is_same_speaker': bool(is_same),
            'similarity': float(similarity),
            'threshold': self.threshold
        }

# Usage
verifier = SpeakerVerifier(embedding_extractor=trainer, threshold=0.6)

# Load audio samples
audio1, sr1 = librosa.load('speaker1_sample1.wav', sr=16000)
audio2, sr2 = librosa.load('speaker1_sample2.wav', sr=16000)

result = verifier.verify(audio1, audio2)

print(f"Same speaker: {result['is_same_speaker']}")
print(f"Similarity: {result['similarity']:.4f}")

Threshold Selection

class ThresholdOptimizer:
    """
    Find optimal verification threshold

    Balances False Acceptance Rate (FAR) and False Rejection Rate (FRR)
    """

    def __init__(self):
        pass

    def compute_eer(self, genuine_scores, impostor_scores):
        """
        Compute Equal Error Rate (EER)

        Args:
            genuine_scores: Similarity scores for same-speaker pairs
            impostor_scores: Similarity scores for different-speaker pairs

        Returns:
            {
                'eer': float,
                'threshold': float
            }
        """
        # Try different thresholds
        # Restrict to plausible cosine similarity range [-1, 1]
        thresholds = np.linspace(-1.0, 1.0, 1000)

        fars = []
        frrs = []

        for threshold in thresholds:
            # False Acceptance: impostor accepted as genuine
            far = np.mean(impostor_scores >= threshold)

            # False Rejection: genuine rejected as impostor
            frr = np.mean(genuine_scores < threshold)

            fars.append(far)
            frrs.append(frr)

        fars = np.array(fars)
        frrs = np.array(frrs)

        # Find EER: point where FAR == FRR
        diff = np.abs(fars - frrs)
        eer_idx = np.argmin(diff)

        eer = (fars[eer_idx] + frrs[eer_idx]) / 2
        eer_threshold = thresholds[eer_idx]

        return {
            'eer': eer,
            'threshold': eer_threshold,
            'far_at_eer': fars[eer_idx],
            'frr_at_eer': frrs[eer_idx]
        }

# Usage
optimizer = ThresholdOptimizer()

# Collect scores from validation set
genuine_scores = []  # Same-speaker pairs
impostor_scores = []  # Different-speaker pairs

# ... collect scores ...

result = optimizer.compute_eer(
    np.array(genuine_scores),
    np.array(impostor_scores)
)

print(f"EER: {result['eer']:.2%}")
print(f"Optimal threshold: {result['threshold']:.4f}")

Speaker Identification

Identify which speaker from a database is speaking.

Database of Speakers

import faiss

class SpeakerDatabase:
    """
    Store and search speaker embeddings

    Uses FAISS for efficient similarity search
    """

    def __init__(self, embedding_dim=512):
        self.embedding_dim = embedding_dim

        # FAISS index for fast similarity search
        self.index = faiss.IndexFlatIP(embedding_dim)  # Inner product (cosine similarity)

        # Metadata: speaker IDs
        self.speaker_ids = []

    def enroll_speaker(self, speaker_id: str, embedding: np.ndarray):
        """
        Enroll a new speaker

        Args:
            speaker_id: Unique speaker identifier
            embedding: Speaker embedding (512-dim)
        """
        # Normalize embedding
        embedding = embedding / np.linalg.norm(embedding)
        embedding = embedding.reshape(1, -1).astype('float32')

        # Add to index
        self.index.add(embedding)

        # Store metadata
        self.speaker_ids.append(speaker_id)

    def identify_speaker(self, query_embedding: np.ndarray, top_k=5):
        """
        Identify speaker from database

        Args:
            query_embedding: Embedding to search for
            top_k: Return top-k most similar speakers

        Returns:
            List of (speaker_id, similarity_score)
        """
        # Normalize query
        query = query_embedding / np.linalg.norm(query_embedding)
        query = query.reshape(1, -1).astype('float32')

        # Search
        similarities, indices = self.index.search(query, top_k)

        # Format results
        results = []
        for similarity, idx in zip(similarities[0], indices[0]):
            if idx < len(self.speaker_ids):
                results.append({
                    'speaker_id': self.speaker_ids[idx],
                    'similarity': float(similarity),
                    'rank': len(results) + 1
                })

        return results

    def get_num_speakers(self):
        """Get number of enrolled speakers"""
        return len(self.speaker_ids)

    def save(self, index_path: str, meta_path: str):
        """Persist FAISS index and metadata"""
        faiss.write_index(self.index, index_path)
        import json
        with open(meta_path, 'w') as f:
            json.dump({'speaker_ids': self.speaker_ids}, f)

    def load(self, index_path: str, meta_path: str):
        """Load FAISS index and metadata"""
        self.index = faiss.read_index(index_path)
        import json
        with open(meta_path, 'r') as f:
            meta = json.load(f)
            self.speaker_ids = meta.get('speaker_ids', [])

    def get_embedding(self, speaker_id: str) -> np.ndarray:
        """
        Retrieve enrolled embedding by speaker_id.
        Note: IndexFlatIP does not store vectors retrievably; in production
        store embeddings separately. This function assumes you maintain a
        parallel mapping. Placeholder returns None.
        """
        return None

# Usage
database = SpeakerDatabase(embedding_dim=512)

# Enroll speakers
for speaker_id in ['alice', 'bob', 'charlie']:
    # Extract embedding from enrollment audio
    audio, _ = librosa.load(f'{speaker_id}_enroll.wav', sr=16000)
    embedding = verifier.extract_embedding(audio)

    database.enroll_speaker(speaker_id, embedding)

print(f"Enrolled {database.get_num_speakers()} speakers")

# Identify speaker from test audio
test_audio, _ = librosa.load('unknown_speaker.wav', sr=16000)
test_embedding = verifier.extract_embedding(test_audio)

results = database.identify_speaker(test_embedding, top_k=3)

print("Top matches:")
for result in results:
    print(f"  {result['rank']}. {result['speaker_id']}: {result['similarity']:.4f}")

Production Deployment

Real-Time Verification API

from fastapi import FastAPI, File, UploadFile
import io

app = FastAPI()

class SpeakerRecognitionService:
    """
    Production speaker recognition service
    """

    def __init__(self):
        # Load model
        self.embedding_extractor = load_pretrained_model()

        # Load speaker database
        self.database = SpeakerDatabase()
        # Load FAISS index and metadata files
        self.database.load('speaker_database.index', 'speaker_database.meta.json')

        # Verifier
        self.verifier = SpeakerVerifier(
            self.embedding_extractor,
            threshold=0.65
        )

    def process_audio_bytes(self, audio_bytes: bytes) -> np.ndarray:
        """Convert uploaded audio to waveform"""
        import soundfile as sf

        audio, sr = sf.read(io.BytesIO(audio_bytes))

        # Resample if needed
        if sr != 16000:
            import librosa
            audio = librosa.resample(audio, orig_sr=sr, target_sr=16000)

        return audio

service = SpeakerRecognitionService()

@app.post("/enroll")
async def enroll_speaker(
    speaker_id: str,
    audio: UploadFile = File(...)
):
    """
    Enroll new speaker

    POST /enroll?speaker_id=alice
    Body: audio file
    """
    # Read audio
    audio_bytes = await audio.read()
    audio_waveform = service.process_audio_bytes(audio_bytes)

    # Extract embedding
    embedding = service.verifier.extract_embedding(audio_waveform)

    # Enroll
    service.database.enroll_speaker(speaker_id, embedding)

    return {
        'status': 'success',
        'speaker_id': speaker_id,
        'total_speakers': service.database.get_num_speakers()
    }

@app.post("/verify")
async def verify_speaker(
    claimed_speaker_id: str,
    audio: UploadFile = File(...)
):
    """
    Verify claimed identity

    POST /verify?claimed_speaker_id=alice
    Body: audio file
    """
    # Process audio
    audio_bytes = await audio.read()
    audio_waveform = service.process_audio_bytes(audio_bytes)

    # Extract embedding
    query_embedding = service.verifier.extract_embedding(audio_waveform)

    # Get enrolled embedding (lookup from database; implement external store in production)
    enrolled_embedding = service.database.get_embedding(claimed_speaker_id)
    if enrolled_embedding is None:
        return {
            'error': 'enrolled embedding not found',
            'claimed_speaker_id': claimed_speaker_id
        }, 404

    # Verify
    similarity = service.verifier.cosine_similarity(query_embedding, enrolled_embedding)
    is_verified = similarity >= service.verifier.threshold

    return {
        'verified': bool(is_verified),
        'similarity': float(similarity),
        'threshold': service.verifier.threshold,
        'claimed_speaker_id': claimed_speaker_id
    }

@app.post("/identify")
async def identify_speaker(audio: UploadFile = File(...)):
    """
    Identify unknown speaker

    POST /identify
    Body: audio file
    """
    # Process audio
    audio_bytes = await audio.read()
    audio_waveform = service.process_audio_bytes(audio_bytes)

    # Extract embedding
    embedding = service.verifier.extract_embedding(audio_waveform)

    # Identify
    matches = service.database.identify_speaker(embedding, top_k=5)

    return {
        'matches': matches
    }

Anti-Spoofing

Detect replay attacks and synthetic voices.

class AntiSpoofingDetector:
    """
    Detect spoofing attacks

    - Replay attacks (recorded audio)
    - Synthetic voices (TTS, deepfakes)
    """

    def __init__(self, model):
        self.model = model

    def detect_spoofing(self, audio):
        """
        Detect if audio is spoofed

        Returns:
            {
                'is_genuine': bool,
                'confidence': float
            }
        """
        # Extract anti-spoofing features
        # E.g., phase information, low-level acoustic features
        features = self._extract_antispoofing_features(audio)

        # Classify
        # is_genuine_prob = self.model.predict(features)
        is_genuine_prob = 0.92  # Placeholder

        return {
            'is_genuine': is_genuine_prob > 0.5,
            'confidence': float(is_genuine_prob)
        }

    def _extract_antispoofing_features(self, audio):
        """
        Extract features for spoofing detection

        - CQCC (Constant Q Cepstral Coefficients)
        - LFCC (Linear Frequency Cepstral Coefficients)
        - Phase information
        """
        # Placeholder
        return None

Real-World Applications

Voice Assistant Personalization

class VoiceAssistantPersonalization:
    """
    Personalize responses based on recognized speaker
    """

    def __init__(self, speaker_recognizer):
        self.recognizer = speaker_recognizer

        # User preferences
        self.user_preferences = {
            'alice': {'music_genre': 'jazz', 'news_source': 'npr'},
            'bob': {'music_genre': 'rock', 'news_source': 'bbc'},
        }

    def process_voice_command(self, audio, command):
        """
        Recognize speaker and personalize response
        """
        # Identify speaker
        embedding = self.recognizer.extract_embedding(audio)
        matches = self.recognizer.database.identify_speaker(embedding, top_k=1)

        if matches and matches[0]['similarity'] > 0.7:
            speaker_id = matches[0]['speaker_id']

            # Get preferences
            prefs = self.user_preferences.get(speaker_id, {})

            # Personalize response based on command
            if 'play music' in command:
                genre = prefs.get('music_genre', 'pop')
                return f"Playing {genre} music for {speaker_id}"

            elif 'news' in command:
                source = prefs.get('news_source', 'default')
                return f"Here's news from {source} for {speaker_id}"

        return "Generic response for unknown user"

Advanced Topics

Speaker Diarization

Segment audio by speaker (“who spoke when”).

class SpeakerDiarizer:
    """
    Speaker diarization: Segment audio by speaker

    Process:
    1. VAD: Detect speech segments
    2. Extract embeddings for each segment
    3. Cluster embeddings → speakers
    4. Assign segments to speakers
    """

    def __init__(self, embedding_extractor):
        self.extractor = embedding_extractor

    def diarize(self, audio, sr=16000, window_sec=2.0):
        """
        Perform speaker diarization

        Args:
            audio: Audio waveform
            sr: Sample rate
            window_sec: Window size for embedding extraction

        Returns:
            List of (start_time, end_time, speaker_id)
        """
        # Step 1: Segment audio into windows
        window_samples = int(window_sec * sr)
        segments = []

        for start in range(0, len(audio) - window_samples, window_samples // 2):
            end = start + window_samples
            segment_audio = audio[start:end]

            # Extract embedding
            embedding = self.extractor.extract_embedding(segment_audio)

            segments.append({
                'start_time': start / sr,
                'end_time': end / sr,
                'embedding': embedding
            })

        # Step 2: Cluster embeddings
        embeddings_matrix = np.array([s['embedding'] for s in segments])
        speaker_labels = self._cluster_embeddings(embeddings_matrix)

        # Step 3: Assign labels to segments
        for segment, label in zip(segments, speaker_labels):
            segment['speaker_id'] = f'speaker_{label}'

        # Step 4: Merge consecutive segments from same speaker
        merged = self._merge_segments(segments)

        return merged

    def _cluster_embeddings(self, embeddings, num_speakers=None):
        """
        Cluster embeddings using spectral clustering

        Args:
            embeddings: (N, embedding_dim) matrix
            num_speakers: Number of speakers (auto-detect if None)

        Returns:
            Speaker labels for each segment
        """
        from sklearn.cluster import SpectralClustering

        if num_speakers is None:
            # Auto-detect number of speakers (simplified)
            num_speakers = self._estimate_num_speakers(embeddings)

        # Cluster
        clustering = SpectralClustering(
            n_clusters=num_speakers,
            affinity='cosine'
        )

        labels = clustering.fit_predict(embeddings)

        return labels

    def _estimate_num_speakers(self, embeddings):
        """Estimate number of speakers (simplified heuristic)"""
        # Use silhouette score to find optimal clusters
        from sklearn.metrics import silhouette_score

        best_score = -1
        best_k = 2

        for k in range(2, min(10, len(embeddings) // 5)):
            try:
                from sklearn.cluster import KMeans
                kmeans = KMeans(n_clusters=k, random_state=42)
                labels = kmeans.fit_predict(embeddings)
                score = silhouette_score(embeddings, labels)

                if score > best_score:
                    best_score = score
                    best_k = k
            except:
                break

        return best_k

    def _merge_segments(self, segments):
        """Merge consecutive segments from same speaker"""
        if not segments:
            return []

        merged = []
        current = {
            'start_time': segments[0]['start_time'],
            'end_time': segments[0]['end_time'],
            'speaker_id': segments[0]['speaker_id']
        }

        for segment in segments[1:]:
            if segment['speaker_id'] == current['speaker_id']:
                # Same speaker, extend segment
                current['end_time'] = segment['end_time']
            else:
                # Different speaker, save current and start new
                merged.append(current)
                current = {
                    'start_time': segment['start_time'],
                    'end_time': segment['end_time'],
                    'speaker_id': segment['speaker_id']
                }

        # Add last segment
        merged.append(current)

        return merged

# Usage
diarizer = SpeakerDiarizer(embedding_extractor=trainer)

audio, sr = librosa.load('meeting_audio.wav', sr=16000)
diarization = diarizer.diarize(audio, sr=sr, window_sec=2.0)

print("Speaker diarization results:")
for segment in diarization:
    print(f"  {segment['start_time']:.1f}s - {segment['end_time']:.1f}s: {segment['speaker_id']}")

Domain Adaptation

Adapt speaker recognition to new domains/conditions.

class DomainAdaptation:
    """
    Adapt speaker embeddings across domains

    Use case: Train on clean speech, deploy on noisy environment
    """

    def __init__(self, base_model):
        self.base_model = base_model

    def extract_domain_adapted_embedding(
        self,
        audio,
        target_domain='noisy'
    ):
        """
        Extract embedding with domain adaptation

        Techniques:
        1. Multi-condition training
        2. Domain adversarial training
        3. Feature normalization
        """
        # Extract base embedding
        features = self._audio_to_features(audio)
        base_embedding = self.base_model(features)

        # Apply domain-specific adaptation
        if target_domain == 'noisy':
            # Normalize to reduce noise impact
            adapted = self._normalize_embedding(base_embedding)
        elif target_domain == 'telephone':
            # Adapt for telephony bandwidth
            adapted = self._bandwidth_adaptation(base_embedding)
        else:
            adapted = base_embedding

        return adapted

    def _normalize_embedding(self, embedding):
        """Length normalization"""
        norm = torch.norm(embedding, p=2, dim=-1, keepdim=True)
        return embedding / norm

    def _bandwidth_adaptation(self, embedding):
        """Adapt for limited bandwidth"""
        # Apply transformation learned for telephony
        # In production: learned linear transformation
        return embedding

Multi-Modal Biometrics

Combine speaker recognition with face recognition.

class MultiModalBiometrics:
    """
    Fuse speaker + face recognition for stronger authentication

    Fusion strategies:
    1. Score-level fusion
    2. Feature-level fusion
    3. Decision-level fusion
    """

    def __init__(self, speaker_verifier, face_verifier):
        self.speaker = speaker_verifier
        self.face = face_verifier

    def verify_multimodal(
        self,
        audio,
        face_image,
        claimed_identity: str,
        fusion_method='score'
    ) -> dict:
        """
        Verify using both voice and face

        Args:
            audio: Audio sample
            face_image: Face image
            claimed_identity: Claimed identity
            fusion_method: 'score', 'feature', or 'decision'

        Returns:
            Verification result
        """
        # Get individual scores
        speaker_result = self.speaker.verify(audio, claimed_identity)
        face_result = self.face.verify(face_image, claimed_identity)

        if fusion_method == 'score':
            # Score-level fusion: weighted combination
            combined_score = (
                0.6 * speaker_result['similarity'] +
                0.4 * face_result['similarity']
            )

            is_verified = combined_score > 0.7

            return {
                'verified': is_verified,
                'combined_score': combined_score,
                'speaker_score': speaker_result['similarity'],
                'face_score': face_result['similarity'],
                'method': 'score_fusion'
            }

        elif fusion_method == 'decision':
            # Decision-level fusion: both must pass
            is_verified = (
                speaker_result['is_same_speaker'] and
                face_result['is_same_person']
            )

            return {
                'verified': is_verified,
                'speaker_verified': speaker_result['is_same_speaker'],
                'face_verified': face_result['is_same_person'],
                'method': 'decision_fusion'
            }

Optimization for Production

Model Compression

Reduce model size for edge deployment.

class CompressedXVector:
    """
    Compressed x-vector for mobile/edge devices

    Techniques:
    1. Quantization (INT8)
    2. Pruning
    3. Knowledge distillation
    """

    def __init__(self, base_model):
        self.base_model = base_model
        self.compressed_model = None

    def quantize_model(self):
        """
        Quantize model to INT8

        Reduces size by 4x with minimal accuracy loss
        """
        import torch.quantization

        # Prepare for quantization
        self.base_model.eval()
        self.base_model.qconfig = torch.quantization.get_default_qconfig('fbgemm')

        # Fuse layers (Conv+BN+ReLU)
        torch.quantization.fuse_modules(
            self.base_model,
            [['conv1', 'bn1', 'relu1']],
            inplace=True
        )

        # Prepare
        torch.quantization.prepare(self.base_model, inplace=True)

        # Calibrate with sample data
        # In production: use representative dataset
        sample_input = torch.randn(10, 300, 40)
        with torch.no_grad():
            self.base_model(sample_input)

        # Convert to quantized model
        self.compressed_model = torch.quantization.convert(self.base_model, inplace=False)

        return self.compressed_model

    def export_to_onnx(self, output_path='speaker_model.onnx'):
        """
        Export to ONNX for cross-platform deployment
        """
        dummy_input = torch.randn(1, 300, 40)

        torch.onnx.export(
            self.compressed_model or self.base_model,
            dummy_input,
            output_path,
            input_names=['mel_spectrogram'],
            output_names=['embedding'],
            dynamic_axes={
                'mel_spectrogram': {1: 'time'},  # Variable length
            }
        )

        print(f"Model exported to {output_path}")

Streaming Enrollment

Enroll speakers incrementally from streaming audio.

class StreamingEnrollment:
    """
    Incrementally build speaker profile from multiple utterances

    Use case: "Say 'Hey Siri' five times to enroll"
    """

    def __init__(self, embedding_extractor, required_utterances=5):
        self.extractor = embedding_extractor
        self.required_utterances = required_utterances
        self.enrollment_sessions = {}

    def start_enrollment(self, speaker_id: str):
        """Start new enrollment session"""
        self.enrollment_sessions[speaker_id] = {
            'embeddings': [],
            'started_at': time.time()
        }

    def add_utterance(self, speaker_id: str, audio):
        """
        Add enrollment utterance

        Returns:
            {
                'progress': int,  # Number of utterances collected
                'required': int,
                'complete': bool
            }
        """
        if speaker_id not in self.enrollment_sessions:
            raise ValueError(f"No enrollment session for {speaker_id}")

        # Extract embedding
        embedding = self.extractor.extract_embedding(audio)

        # Add to session
        session = self.enrollment_sessions[speaker_id]
        session['embeddings'].append(embedding)

        progress = len(session['embeddings'])
        complete = progress >= self.required_utterances

        return {
            'progress': progress,
            'required': self.required_utterances,
            'complete': complete,
            'speaker_id': speaker_id
        }

    def finalize_enrollment(self, speaker_id: str) -> np.ndarray:
        """
        Compute final speaker embedding

        Strategy: Average embeddings from all utterances
        """
        session = self.enrollment_sessions[speaker_id]

        if len(session['embeddings']) < self.required_utterances:
            raise ValueError(f"Insufficient utterances: {len(session['embeddings'])}/{self.required_utterances}")

        # Average embeddings
        embeddings_matrix = np.array(session['embeddings'])
        final_embedding = np.mean(embeddings_matrix, axis=0)

        # Normalize
        final_embedding = final_embedding / np.linalg.norm(final_embedding)

        # Clean up session
        del self.enrollment_sessions[speaker_id]

        return final_embedding

# Usage
enrollment = StreamingEnrollment(embedding_extractor=trainer, required_utterances=5)

# Start enrollment
enrollment.start_enrollment('alice')

# Collect utterances
for i in range(5):
    audio, _ = librosa.load(f'alice_utterance_{i}.wav', sr=16000)
    result = enrollment.add_utterance('alice', audio)
    print(f"Progress: {result['progress']}/{result['required']}")

# Finalize
if result['complete']:
    final_embedding = enrollment.finalize_enrollment('alice')
    print(f"Enrollment complete! Embedding shape: {final_embedding.shape}")

Evaluation Metrics

Performance Metrics

class SpeakerRecognitionEvaluator:
    """
    Comprehensive evaluation for speaker recognition
    """

    def __init__(self):
        pass

    def compute_eer_and_det(
        self,
        genuine_scores: np.ndarray,
        impostor_scores: np.ndarray
    ) -> dict:
        """
        Compute EER and DET curve

        Args:
            genuine_scores: Similarity scores for same-speaker pairs
            impostor_scores: Similarity scores for different-speaker pairs

        Returns:
            Evaluation metrics and DET curve data
        """
        thresholds = np.linspace(-1, 1, 1000)

        fars = []
        frrs = []

        for threshold in thresholds:
            # False Accept Rate
            far = np.mean(impostor_scores >= threshold)

            # False Reject Rate
            frr = np.mean(genuine_scores < threshold)

            fars.append(far)
            frrs.append(frr)

        fars = np.array(fars)
        frrs = np.array(frrs)

        # Equal Error Rate
        eer_idx = np.argmin(np.abs(fars - frrs))
        eer = (fars[eer_idx] + frrs[eer_idx]) / 2
        eer_threshold = thresholds[eer_idx]

        # Detection Cost Function (DCF)
        # Weighted combination of FAR and FRR
        c_miss = 1.0
        c_fa = 1.0
        p_target = 0.01  # Prior probability of target speaker

        dcf = c_miss * frrs * p_target + c_fa * fars * (1 - p_target)
        min_dcf = np.min(dcf)

        return {
            'eer': eer,
            'eer_threshold': eer_threshold,
            'min_dcf': min_dcf,
            'det_curve': {
                'fars': fars,
                'frrs': frrs,
                'thresholds': thresholds
            }
        }

    def plot_det_curve(self, fars, frrs):
        """
        Plot Detection Error Tradeoff (DET) curve
        """
        import matplotlib.pyplot as plt

        plt.figure(figsize=(8, 6))
        plt.plot(fars * 100, frrs * 100)
        plt.xlabel('False Acceptance Rate (%)')
        plt.ylabel('False Rejection Rate (%)')
        plt.title('DET Curve')
        plt.grid(True)
        plt.xscale('log')
        plt.yscale('log')
        plt.show()

Security Considerations

Attack Vectors

  1. Replay Attack: Recording and replaying legitimate user’s voice
  2. Synthesis Attack: TTS or voice cloning
  3. Impersonation: Human mimicking target speaker
  4. Adversarial Audio: Crafted audio to fool model

Mitigation Strategies

class SecurityEnhancedVerifier:
    """
    Speaker verification with security enhancements
    """

    def __init__(self, verifier, anti_spoofing_detector):
        self.verifier = verifier
        self.anti_spoofing = anti_spoofing_detector
        self.challenge_phrases = [
            "My voice is my password",
            "Today is a beautiful day",
            "Open sesame"
        ]

    def verify_with_liveness(
        self,
        audio,
        claimed_identity: str,
        expected_phrase: str = None
    ) -> dict:
        """
        Verify with liveness detection

        Steps:
        1. Anti-spoofing check
        2. Speaker verification
        3. Optional: Speech content verification
        """
        # Step 1: Anti-spoofing
        spoofing_result = self.anti_spoofing.detect_spoofing(audio)

        if not spoofing_result['is_genuine']:
            return {
                'verified': False,
                'reason': 'spoofing_detected',
                'spoofing_confidence': spoofing_result['confidence']
            }

        # Step 2: Speaker verification
        verification_result = self.verifier.verify(audio, claimed_identity)

        if not verification_result['is_same_speaker']:
            return {
                'verified': False,
                'reason': 'speaker_mismatch',
                'similarity': verification_result['similarity']
            }

        # Step 3: Optional phrase verification
        if expected_phrase:
            # Use ASR to verify phrase
            # transcription = asr_model.transcribe(audio)
            # phrase_match = transcription.lower() == expected_phrase.lower()
            phrase_match = True  # Placeholder

            if not phrase_match:
                return {
                    'verified': False,
                    'reason': 'phrase_mismatch'
                }

        return {
            'verified': True,
            'similarity': verification_result['similarity'],
            'spoofing_confidence': spoofing_result['confidence']
        }

Key Takeaways

✅ Speaker embeddings (x-vectors) map audio → fixed vector
✅ Verification (1:1) vs Identification (1:N)
✅ Cosine similarity for comparing embeddings
✅ EER (Equal Error Rate) balances FAR and FRR
✅ FAISS enables fast similarity search for millions of speakers
✅ Speaker diarization segments audio by speaker
✅ Domain adaptation critical for robustness across conditions
✅ Multi-modal biometrics combine voice + face for stronger security
✅ Model compression enables edge deployment
✅ Anti-spoofing critical for security applications
✅ Streaming enrollment builds profiles incrementally
✅ Production systems need enrollment, verification, and identification APIs
✅ Real-world uses: Voice assistants, call centers, security, forensics

Originally published at: arunbaby.com/speech-tech/0005-speaker-recognition

If you found this helpful, consider sharing it with others who might benefit.

Related across topics

Maximum Subarray (Kadane’s Algorithm)

23 minute read

Master the pattern behind online algorithms, streaming analytics, and dynamic programming, a single elegant idea powering countless production systems.

Speaker Recognition & Verification

21 minute read

How voice assistants recognize who’s speaking, the biometric authentication powering “Hey Alexa” and personalized experiences.
